Specifications
coal slime dryer machine1.wide range of application
2.excellent drying effect
3.lignite coal is feasible too
coal slime dryer
Operation cost and profits analysis report of coal slime dryer
Zhengzhou Weilite mechanical plant has more than 30 years experiences in drying and dehumidifying technology accumulation, relying on professional advantage and
scientific technological innovation, Has been successfully developed to produce high bond material drying
equipment for coal, peat, sludge, gypsum and high humidity, for each area, the different nature of the peat coal,
sludge enjoy the corollary equipment and drying technology professional, stable operation, strong pertinence,
simple operation, low operation cost lead to a significant drying effect.
25% moisture content of coal slime as example, drying to 10-15% of finished product coal, 0.88 tons per ton
after drying; Currently ,coal price in 200 yuan/tons, after drying can be sold for 450 yuan per ton. To put into
production one day processing 300 tons of coal slime dryer production line, equipment operation cost, profit
analysis is as follows:
coal slime dryer operation cost analysis
1, the staff, every three to four people, two class salary: 350 yuan/day,
electricity: total power 52.5 KW, 52.5 KW * 0.7 = 36.75 degrees per hour, boot up to 20 hours a day,
so: 735 x 0.9 yuan/degrees = 661.50 yuan.
2, fuel: every tons of coal drying with BiaoMei about 18 kg, at $500 per ton, 5.4 tons of coal used in every day,
so: 2700 yuan. Subtotal: $3711.5.
coal slime dryer profits analysis
1, every day purchase 300 tons of coal, after drying production 264 tons, according to the price of 400 yuan per
ton, so: 105600 yuan.
2, coal slime, 200 yuan per ton, purchase 300 tons, so: 6000 yuan.
3, comprehensive profit: 105600-60000-3711.50 = 41888.5 yuan/day
Structure of coal slime dryer machine
Coal dryer equipment is mainly composed of heat source equipment (stove), conveyor, scattering device,
appenging machine, feeder, rotary drying drum, transmission mechanism, discharger, grinder, draught equipment,
dust removal equipment and electronic control system.
Technology parameter of coal slime rotary drum dryer
| Model | Gradient(%) | Rotate speed(r/min) | Inlet air temperature(°c) | Powder(kw) | Capacity(t/h) | Weight(t) |
| Φ600x6000 | 3-5 | 3-8 | ≤700 | 3 | 0.5-1.5 | 2.9 |
| Φ800x8000 | 3-5 | 3-8 | ≤700 | 4 | 0.8-2.0 | 3.5 |
| Φ 800x10000 | 3-5 | 3-8 | ≤700 | 4 | 0.8-2.5 | 4.5 |
| Φ 3000x20000 | 3-5 | 1.5-5 | ≤800 | 55 | 25-35 | 78 |
| Φ 3000x25000 | 3-5 | 1.5-5 | ≤800 | 75 | 32-40 | 104.9 |
Application of coal slime dryer machine
Coal dryer equipment is mainly used for the coal industry, coal, peat, coal slime flotation concentrate, mixed
concentrate, tailings and other material drying.
parts and workshop show of coal slime rotary dryer
avaliable sea port
qingdao,shanghai,tianjin
note:
1, because the coal price at each district is different, the finished product coal price is different also, local
workers wages, electricity prices vary, according to local market price calculation, please.
2, coal drying equipment operation experience face-to-face.
More coal slime dryer details and coal drying production plan
If you have any quetion , pl feel free to contact me, I'm Steve, ready to serve you!
