OUTDOOR LED MODULE P10 P16 P6 P3 P8
- 100000000 Piece / Pieces per Month
- SHENZHEN MUMBAI HONG KONG
- T/T
Product Details
Model Number: | P10 | Chip Material: | AlGaInP | Emitting Color: | Tri-Color(Red-Blue-Green) |
Luminous Intensity: | 6000-7000mcd | Luminous Flux(lm): | 54lm | Optical Attenuation(%): | 1 |
Power: | 10W | Power Dissipation: | 0.72 | Color Rendering Index(Ra): | 256 |
Color Temperature: | 0-128 | Operating Temperature(℃): | 35, 85 | Storage Temperature(℃): | 35, 85 |
Place of Origin: | Guangdong, China | Brand Name: | SAIMPEX | Certification: | CE |
Product Description
Wholesale hd outdoor full color SMD LED Module P10
Products function introduction
1) High intensity and can be adjusted, so can meet the request of the customers according the application environment.
2) Best equality, have the excellent consistency of light.
3) To pictures and character, have clear, exquisite and real display effect.
4) Big viewing angle to 120-150 degree at horizontal line, 120-150 degree at vertical line, you can see at every angle at this range, no picture change, no color excursion.
5) Can repair each led lamps, so the cost of maintain is lower, and easy to repair.
Technical Specification OF P10 SMD LED MODULE
Item | Parameter | |||
Pixel Pitch | 10mm | |||
LED Encapsulation | 1R1G1B | |||
LED Chips | Epistar + Silan | |||
Module resolution | 32dots*16dots | |||
Module size(mm*mm) | 320mm*160mm | |||
Pixel density | 10000dots/m² | |||
Weight | 0.6KG | |||
Drive Method: | 1/2scanning | |||
Brand of power supply | CL 5V~40A | |||
Gray Scale | Recommended 256 level | |||
The best viewing angle | Horizontal:140 Vertical:90 | |||
Max Power Consumption | 750W/ m² | |||
Control Mode | Video frequency synchronization | |||
Optimal Viewing Distance | ≥10m | |||
Brightness | ≥7500cd/m² | |||
Blind Spot Rate | <0.0001 | |||
Brightness Control | 0-255 Grade | |||
Contrast | 100 levels adjustable | |||
Earth Leakage Current | <2mA | |||
MTBF | >5000Hours | |||
Lifespan | >100000Hours | |||
Power Supply Mode | AC220V/50HZ or AC110V/60HZ | |||
Protection Level | IP65 | |||
Humidity | 0%~90% | |||
Operating System | Windows98/me/2000/NT/XP | |||
Operating temperture | Operation:-30°C~+60°C |
1) . Packing : Our goods are packed with carton ,wooden case, flight case or according customer's request
2) . Shipping: Shipped by air/ sea
3) . box size - 46cm*39cm*36cm ( 40pcs/box )
4). Weight - 21.5kg/box
Warranty:
We guarantee all our displays, modules, parts for one full years. During this time, we will replace or amend all our goods for free if there is something wrong with them. We provide lifetime maintenance and charge only for the raw materials. We provide technology training for free, which contains the operation and maintenance training of the LED screens in the factory. We also provide the operation manual, software, test report and so on. Any associated CAD drawing on how to fix up the display and some other expert suggestion will be provided.
Technology Training
1. We provide the technology training for free, which contains the operation training and maintenance training in the factory.
2. We will send our engineers to your country by negotiation.
Documents and Certification:
1. We provide the operation manual, software, test report and so on.
2. We can also provide all kinds of certification such as CE, UL and so on.
CAD Drawing and Fixing 1. We provide CAD drawing on how to fix up the display for free and some other expert suggestion.
2. We will send our engineers to your place if we are expected after our negotiation.
Additional service: We provide you the forwarding information, and some other information ,such as flight box, structure information for your reference for free.
Panyment Different countries payment different ways
Sai Export & Import is a leading LED display manufacturer and solution
5. Equipped with state of the full-automatic machinery for SMT, cabinet aging testing, packaging, silicone
potting, wave-soldering, auto-insertion, reflow oven.
6. Passed 3C, ISO9001:2008, ROHS and CE certificates.
7. More than 10 Overseas Exhibition every year.
2. Mobile Phone | 91-9767474030 |
3. Skype | sai.gade2 |
100% Best Quality , We Sale Only Best Quality
Q: Do you accept customize size?
A: Yes, of cause. Just tell us your request, we will do the suitable one to you.
Q: What is the led chip packing?
A:Indoor:SMD 3528/2121/1010; Outdoor:546 oval lamp/346 oval lamp.
Q:Why Choose us?
-We are Alibaba Assessed Gold Supplier
-More professional, best service
-100% QC inspection before shippment.
-We are direct factory manufacturer for led display, so quick delivery is no problem.
