Plate type quick Changing screen changer
Description
Plate type quick changing screen changer is designed with double working positions.It achieves the quick changing between the working position and standby position unit with accumulator.
Application
• Granulating,pipe making ,film blowing,plate making,collosols,rubber and chemical fiber.
• Production of various thermoplastic and filtration of mixture material.
Performance Features
High performance/price ratio,non-stop screen changing,labor-saving.
Large filtering area,high efficiency
High pressure resistance,high temperature resistance,no material leakage.
Easy operation,easy maintenance.
Type |
Dimensions L/W/H(mm) |
Screen Dm(mm) |
Suitable materials |
Capacity(kg/h) |
Heating Power (kw) |
Pressure(Mpa) |
DHB-70 |
735*130*197 |
Ø70 |
Almost all polymers |
60-250 |
4.4 |
50 |
DHB-100 |
900*140*257 |
Ø100 |
Almost all polymers |
110-400 |
6.8 |
50 |
DHB-120 |
950*155*297 |
Ø120 |
Almost all polymers |
140-550 |
8.6 |
50 |
DHB-150 |
1180*170*347 |
Ø150 |
Almost all polymers |
200-800 |
9.8 |
50 |
DHB-170 |
1230*190*386 |
Ø165 |
Almost all polymers |
300-1000 |
10.6 |
50 |
DHB-200 |
1380*230*450 |
Ø200 |
Almost all polymers |
400-1200 |
12 |
50 |
DHB-250 |
1400*240*438 |
Ø250 |
Almost all polymers |
600-1800 |
16.4 |
50 |
DHB-300 |
1590*268*526 |
Ø300 |
Almost all polymers |
700-2100 |
16.4 |
50 |
DHB-330 |
1760*300*546 |
Ø330 |
Almost all polymers |
800-2300 |
16.4 |
50 |
Why you Should choose us!
1.We are factory,the price is cheaper than the foreign trade company
2.We are original,the design is from our own research group.
3.We have more than 30 years experience,is a strong company.
4.We are professional ,we only do screen changer,that make us deeper than others.
5.We have many years foreign trade ,liked and relied widely by the foreign friends.
Detail:Presales service:introducing in detail features and application of the products to customerSelecting economical and practical machine & equipment for customerProviding operation data of the related machine & equipment Providing means of trial performance for customer Sales service:Recommending engineering conditions required for installation of the machine & equipmentCommunicating in time the manufacturing progress of the machine with userProviding assistance in technical conditions, screw combination and barrel disposition needed for productAfter-sales service:Providing on-the-spot technical assistance in installation and trainingFilling in detail customer’s informationProviding long-term maintenance service and spare partsGiving technical support to customer for developing new productProviding free maintenance for a year
Attached Knowledge
What is screen changer?
Screen changer includes one or more filter devices. When the polymer fluid flow enters the filter device, the contaminants in the melt is blocked in one side of the filter. The filter is supported by a breaker plate, while the breaker plates are installed in the support carriage; support carriage parts can move, stay in the work place or non-working position.
Screen changer is available supporting the device as following: extruder, melt pump, reactor or other extrusion lines. It can be used to filter any type of polymer and thermoplastic.
Why you need melt filtration device?
As quality specifications become tighter and the need to use more recycled materials becomes more prominent, more and more extrusion processors are examining their options in melt-filtration technology. There are three basic reasons why you need melt filtration:
1. Product quality specifications mandate visual or mechanical properties that cannot be maintained without filtration.
2. Downstream equipment may become damaged by contaminants in the melt.
3. Additional melt pressure is needed to improve melt quality.
It is likely that most extrusion processors will fit into one of the above categories, and that they will find a simple breaker plate unsatisfactory due to the time required disassembling and reassembling the device. The alternatives considered here are various types of screen changers, though other types of filters may be used for special purposes, like high output rates and very tight filtration requirements.
Common uses for screen changers are:
Bulk polymer production from a reactor i.e. producing pellets.
Extrusion lines for compounding polymers, blown film, cast film, sheet, pipes, profiles, plastics recycling.
Different types of Screen Changers are available, to cater for different applications and process requirements. Manual type or slow speed screen changers require the production line to be stopped for a short time to enable the filter to be changed, other types, operating at high speed, can change filter without stopping or slowing down the extrusion process.
For the production of blow film, sheet, pipes, etc, continuous flow screen changers are the most suitable type as the melt continues to flow during a screen change.
Each type of Screen Changer is available in different sizes, to cater for different output requirements. Anji Screen Changers are available from 30mm diameter for polymer outputs of 100 kg/h to the massive Extended Area for outputs up to 60,000 kg/h. For new or existing lines, Anji can design and manufacture adaptors, which may be required to connect the Screen Changer to the rest of the line.
How to choose a suitable screen changer?
As for screen changer, we need to be told as follow:
1. screw diameter;
2. Is the extruder single screw or twin screw?
3. raw material;
4. final product (granulating, monofilament or others);
5. Output;
6. maximum pressure;
7. screen change interval;
8. the screen diameter of your current screen changer;
9. have a melt pump or not.
According to the technical feedback, we will suggest the screen changer that more suitable your processing requirement.
