1, we can produce any kinds of ceramic fiber plates
2,ceramic insulated fiber plates/papers
3, High temperature insulation
Features
1.Good thermal shock resistance
2. High quality of flexibility and tear resistance
3.Excellent electric insulation and sound absorbability
4.Low thermal capacity and low coefficient of thermal conductivity
5.Non-asbestos, resistance to erosion does not react with aluminum liquid
Main Features: | |||
Temperatures |
1260°C |
1350°C |
|
Normal characters(23°C/related humidity 50%) | |||
Color |
White |
White |
|
Bulk density(average)kg/m3 |
165--180 |
180--220 |
|
Tensile strength kN/m |
0.30---1.2 |
0.30—1.2 |
|
0.5mm |
>0.20 |
>0.20 |
|
1mm |
>0.32 |
>0.32 |
|
2mm |
>0.52 |
>0.52 |
|
3mm—6mm |
>0.66 |
>0.66 |
|
Hign temperature features | |||
Ablation volume |
<8% |
<8% |
|
Thermal conductivity(The average temperature in the following) | |||
25°CW/m.k |
0.06 |
0.06 |
|
400°CW/m.k |
0.09 |
0.08 |
|
600°CW/m.k |
0.12 |
0.11 |
|
800°CW/m.k |
0.17 |
0.16 |
|
1000°C°CW/m.k |
0.03—0.21 |
0.03—0.21 |
|
Linear shrinkage(Category temperature) |
<4% |
<4% |
|
Chemical composition | |||
SiO2+ Al2O3 |
>97% |
>97% |
|
Al2O3 |
>45% |
>52% |
|
...
