High quality Online conductivity meter/EC controller/EC probe/EC sensor LH-C230
Feature:
This instrument is a panel instrument for on-line monitoring of industrial process conductivity. Range switch over and constant check can both be freely set and adjusted through the operation component on the rear panel; unique signal collecting and processing technology and special thick film circuit are adopted to make measurement accurate and operation stable; there are also other features such as linearized data, automatic temperature compensation, not subject to the length change of cable and maintenance-free. It's an ideal auxiliary instrument of various types of small pure water equipment.
Technical Data:
Measurement range: |
0~20 0~200 0~2000μS/cm |
Accuracy |
1.5% (FS) |
Stability |
±2 × 10-3 (FS) / 24h |
Auxiliary electrode |
Plastic structure; constant: 1.0cm-1 |
Temperature compensation component |
NTC |
Medium temperature |
5~50ºC |
Thread dimension |
1/2"pipe thread |
Medium pressure |
0~0.5Mpa |
Cable composition |
Quad cable, copper mesh and foil shielded plastic jacket |
Cable length |
5m or on other agreement (5~30m) |
Temperature compensation |
Automatic compensation, with 25ºC as the reference temperature |
Display |
3.5-bit LCD |
Power supply |
AC 220V ±10% 50Hz |
Power consumption |
≤1W |
Environment conditions |
(1) Temperature: 5~50ºC (2) Humidity: ≤85%RH |
Dimensions |
48X96X100mm (heightXwidthXdepth) |
Slot dimensions for installation |
45X91mm (heightXwidth) |
