Biomass Charcoal Powder Briquette Machine
1.Introduction of the Biomass Charcoal Powder Briquette Machine
Biomass charcoal powder briquette machine can press charcoal powder ,metal powder,coal powder,coke powder and other materials into ball shape. Because of Mandatory squeeze of the roll, products features of highdensity, high strength,
high hardness, high features, and rollers adopt 650mn hard wear resistance materials, which improve rollers' service life greatly.
2.Application of Biomass Charcoal Powder Briquette Machine
All powder materials, can use coal press machine press ball. Such as:Charcoal powder Coal powder, coke powder,
ferrous & non-ferrous metal ore powder, iron oxide, dust, sludge, refractories and so on.
3.Work principal of Biomass Charcoal Powder Briquette Machine
Motive power will transmit to two rollers through the reducer synchronously and make them rotate oppositely. Materials enter into ball mode naturally, with rollers rotation, pressure of materials bearing becomes larger. When arriving at two rollers contact point, materials bearing pressure reaches peak. Under the tremendous pressure, materials become ball shape from powder shape.
Pakaging of the Biomass Charcoal Powder Briquette Machine
Coconut Shell Charcoal Briquette Making Machine | |||||||
Model |
WLXM-360 |
WLXM-400 |
WLXM-500 |
WLXM-650 |
WLXM-750 |
WLXM-850 |
WLXM-1250 |
Capacity(T/H) |
2-4 |
6-8 |
8-11 |
13-18 |
18-25 |
25-35 |
40-70 |
Rolling width(mm) |
250 |
280 |
300 |
336 |
400 |
500 |
650 |
Roller diameter(mm) |
360 |
400 |
500 |
650 |
750 |
850 |
1250 |
Motor Powder(kw) |
7.5 |
11-15 |
18.5-22 |
20-30 |
45 |
75 |
130 |
Speed(r/min) |
18 |
15 |
13 |
13 |
13 |
10 |
10 |
Reducer gear |
ZQ350 |
ZQ400 |
ZQ500 |
ZQ650 |
ZQ750 |
ZQ850 |
ZQ1250 |
Sphere size |
Custom-made (Commonly used 30mm-60mm) |
||||||
FAQ of Biomass Charcoal Powder Briquette Machine
1. How much is the raw material moisture to shape right ? What is the special requirement for raw material?
- The moisture of raw material general control in 8% to 12%. The diameter of the raw material must be smaller than 5 mm.
2. What are the specifications of finished briquettes?
- According to the needs of customers, we can manufacture different specifications of the mold.
3. Whether you need drying after forming briquettes?
- You should better dry the finished briquettes. Drying methods usually use mesh belt dryer for drying.
Successful Case of the Biomass Charcoal Powder Briquette Machine
Zhengzhou Weilite Machinery Equipment Co., Ltd. is a manufacturer and exporter oriented enterprise. Our company produces large and medium-sized mining machinery, metallurgical equipment, building materials; our main products are briquette machine, dryer, crusher, sand washing machine, conveyor belt, grinding mill etc. All of them have enjoyed great popularity in world markets.
Contact Preson:Shayne Wang
Tel:+85 0371 86687769
Mobile:+86 15238019501
Skype:shaynewang123
Website: /
