Specifications
1 Power: 400W,1000W etc.2 Resistance: 1ohm ~500ohm
3 Correspod to GB/T5729-94
4 ISO RoHS
5 we supply to the military to
Some parts of our certificates
Advantage of choosing our company and products: 1. Sichuan qixing electronic co. ltd. is a technical factory of mainly manufacturing and develop high power resistor,wire-wound potentiometer,metal glass glaze potentiometer,carbon film potentiometer,precision parts and AC power noise filter. 2. The established maxim of our company is technical innovation, keeping improvement and meet customer demands. 3. Rich and varied goods is your selection guide. High quality is absolutely the credibility of the guarantee. Reasonable price is your final choice. 4. Our products is also used in the field of the military industry .Our factory are continuing to offer a great deal of qualified goods in the field of the military industry . |
Electrical Characteristics
Range of nominal resistance: 1 ~500Ω
Frequency range: 0~2GHz
Insulation resistance: ≥ 1GΩ
Resistance tolerance: ±5%
Standing wave ratio: 1.2~1.3
Withstand voltage: 500V/1 mm (Substrate thickness)
Environment Characteristics
Rated power: 1~1000W (70°C)
TCR: ±300×10-6/°C
Moisture proof (GJB306A-96-Method106): ΔR≤±5%R
Test at low temperature (-55°C, 24h): ΔR≤±5%R
Collision: ΔR≤±3%R
Temperature range: -55°C~+165°C
Temperature shock (-55°C/+125°C, 3 times): ΔR≤±5%R
Vibration (10-500HZ, 0.75mm, 6h): ΔR≤±3%R, No mechanical damage
Load life (96): ΔR≤±5%
Physical Characteristics
Terminal strength (10N, 5s): No loosening or fall-out
Solderability (240°C, 3s): Coverage area of tin layer: 95%
Engaged in civil and war industrial products for many years, we enfore ISO9001, ISO2000 quality control systems strictly. Our products are widely used in electronic communication products, instrument measuring appliances, cable TV equipments, electrician products, color television, color ... View detail
•Products of special resistance and specifications are provided.
•Products of special standing wave ratio should be given a clear indication in contracts.
•Special requirements of standing wave ration is tested and chosen only for products of 50Ω.
•Products are corresponded to the standard of GB/T5729-94.
•Any special requirement is appreciated.
