BONENS RIG02 High-power Resistor 1W,3W ,5W

FOB Price

Negotiable / Piece

100 Pieces(Min.Order)

Supply Ability 10000 Piece / Pieces per Month
Port shenzhen
Payment TermsCredit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Sichuan, China	Brand Name	Bonens
Model Number	RIG02 resistor	Type	Variable Resistor
Technology	Cermet	Package Type	Throught Hole
Resistance	1~500Ω	Resistance Tolerance	±5%
Rated Power	1~1000W	Temperature Coefficient	±300*10-6/℃
Operating Temperature	-55℃~+165℃

Product Description

Specifications

1,high power resistor
2,10ohm--50ohms
3,RoHS compliant
4,RUV certification
5,free sample and high quality

•Products of special resistance and specifications are provided.

•Products of special standing wave ratio should be given a clear indication in contracts.

•Special requirements of standing wave ration is tested and chosen only for products of 50Ω.

•Products are corresponded to the standard of GB/T5729-94.

•Any special requirement is appreciated.

Electrical Characteristics

Range of nominal resistance: 1 ~500Ω

Frequency range: 0~2GHz

Insulation resistance: ≥ 1GΩ

Resistance tolerance: ±5%

Standing wave ratio: 1.2~1.3

Withstand voltage: 500V/1 mm (Substrate thickness)

Environment Characteristics

Rated power: 1~1000W (70°C)

TCR: ±300×10^-6/°C

Moisture proof (GJB306A-96-Method106): ΔR≤±5%R

Test at low temperature (-55°C, 24h): ΔR≤±5%R

Collision: ΔR≤±3%R

Temperature range: -55°C~+165°C

Temperature shock (-55°C/+125°C, 3 times): ΔR≤±5%R

Vibration (10-500HZ, 0.75mm, 6h): ΔR≤±3%R, No mechanical damage

Load life (96): ΔR≤±5%

Some parts of our certificates

Advantage of choosing our company and products:

Sichuan qixing electronic co. ltd. is a technical factory of mainly manufacturing and develop high power resistor,wire-wound potentiometer,metal glass glaze potentiometer,carbon film potentiometer,precision parts and AC power noise filter.
The established maxim of our company is technical innovation, keeping improvement and meet customer demands.
Rich and varied goods is your selection guide. High quality is absolutely the credibility of the guarantee. Reasonable price is your final choice.
Our products is also used in the field of the military industry .Our factory are continuing to offer a great deal of qualified goods in the field of the military industry .

Our partners:

CHANGHONG

TAIWAN KEZHENGXIN ELECTRONICS CO.

XI’AN HONGXING ELECTRONICS CO.

JIALING MOTORCYCLE

KLS ELECTRONIC CO., LTD.

The Scope of Products:

The Work Flow:
