Linear Potentiometer 3006P-T Micro Potentiometer B500k Potentiometer 24v Motor With Potentiometer

Linear Potentiometer 3006P-T Micro Potentiometer B500k Potentiometer 24v Motor With Potentiometer thumbnail-1
Linear Potentiometer 3006P-T Micro Potentiometer B500k Potentiometer 24v Motor With Potentiometer photo-1
Negotiable MOQ: 100 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Sichuan, China
Brand Name:
Bonens
Model Number:
3006 POTENTIOMETER
Contact Supplier Request Quote Chat Now
Sichuan Qixing Electronics Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Sichuan, China
Brand Name Bonens
Model Number 3006 POTENTIOMETER
Type Trimming Potentiometer
Technology Ceramic Composition
Resistance 10Ω~5MΩ
Resistance Tolerance ±10%
Rated Power 0.5W
Max. Operating Voltage 640V
Operating Temperature -55°C~+125°C

Specifications

1.24v motor with potentiometer
2.3006P-T potentiometer
3.Healthy goods
4Offer goods of special resistance

◊ Details of Pictures:



linear potentiometer 3006P-T micro potentiometer b500k potentiometer 24v motor with potentiometerlinear potentiometer 3006P-T micro potentiometer b500k potentiometer 24v motor with potentiometer



◊ Mechanical Parameter:







Electrical Characteristics

Range of nominal resistance

10Ω~5MΩ

Resistance tolerance


±10%

Terminal resistance


≤±1%R or 2Ω

Contact resistance variation (CRV)


≤±1%R or 3Ω

Insulation resistance


≥ 1GΩ (100V AC)

Withstand voltage


640V (DC or AC peak value)

Effective electrical travel


≥70% of mechanical travel





Environment Characteristics

Rated power

0.5W ( 300V max)

Temp erature range


-55°C~+125°C

TCR


±250×10-6/°C

Collision (390m/S2, 4000 times)


ΔR≤±1%R

Vibration (10-500HZ, 0.75mm, 6h)


ΔR≤±1%R, ΔUab/Uac≤±2%R, Electrical break≤100μS

Temperature variation (-55°C/30min,
 +125°C/30min, 5 cycles)

ΔR≤±2%R,
 ΔUab/Uac≤±2%R

Climate category (IEC68-2-2)


ΔR≤± (5%R+0.1Ω),Insulation Resistance≥100MΩ

Electrical endurance (0.5W, 1000h)


ΔR≤± (5%R+0.1Ω),CRV≤±3%R or 5Ω

Mechanical endurance (200 cycles)


ΔR≤± (10%R+0.5Ω), CRV≤±3%R or 5Ω

Steady damp heat (IEC68-2-3, Ca, 96h)


ΔR≤± (5%R+0.1Ω), Insulation Resistance≥100MΩ



Physical Characteristics

Total mechanical travel

22 ° ±  2°

Starting torque


≤35mN.m

Standard package


 25 pcs /tube



Products of special resistance and specifications are provided.



•Products with TCR of 100ppM are provided



•Products with linear accuracy of ±0.25% are provided.



•Products are corresponded to the general specifications of GB/15299-94





◊    Work Flow

 linear potentiometer 3006P-T micro potentiometer b500k potentiometer 24v motor with potentiometerlinear potentiometer 3006P-T micro potentiometer b500k potentiometer 24v motor with potentiometer



◊ Main product





 ◊ Packaging

 linear potentiometer 3006P-T micro potentiometer b500k potentiometer 24v motor with potentiometer



◊ Certificate





 linear potentiometer 3006P-T micro potentiometer b500k potentiometer 24v motor with potentiometerlinear potentiometer 3006P-T micro potentiometer b500k potentiometer 24v motor with potentiometerlinear potentiometer 3006P-T micro potentiometer b500k potentiometer 24v motor with potentiometerlinear potentiometer 3006P-T micro potentiometer b500k potentiometer 24v motor with potentiometer

   For more information, pls don't hesitate to contact us!

                        linear potentiometer 3006P-T micro potentiometer b500k potentiometer 24v motor with potentiometer
