BONENS 2WX20 Precision Potentiometer Trimpot 500V 0.5W

Name: BONENS 2WX20 Precision Potentiometer Trimpot 500V 0.5W
Brand: BONENS
SKU: 101976563
Availability: InStock

Negotiable MOQ: 100 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Sichuan, China

Brand Name:

BONENS

Model Number:

2WX20 potentiometer

Sichuan Qixing Electronics Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Sichuan, China

Brand Name BONENS

Model Number 2WX20 potentiometer

Type Rotary Potentiometer

Technology Metal Alloy

Resistance 100Ω~10KΩ

Resistance Tolerance ±2%, ±5%

Rated Power 0.5W

Max. Operating Voltage 500V

Operating Temperature -55°C~+125°C

Specifications

1,WX20 potentiometer
2,100 ohm~10k ohm
3,supply for military field
4,RoHS compliant
5,ISO9001 certification

Details of Products:

Electrical Characteristics	Range of nominal resistance	100Ω~10KΩ
	Resistance tolerance
		±2%, ±5%

	Terminal resistance
	Terminal resistance	≤±0.5%R or 10Ω
	Peak Noise
	Peak Noise	≤100Ω

	Linear accurancy	±0.5%, ±0.3%

	Insulation resistance
	Insulation resistance	≥ 500MΩ (100V AC)
	Withstand voltage
	Withstand voltage	500V (DC or AC peak value)
	Electrical angle	330° ± 10 °

	Rated power	0.5W ( 70 °C )
	Temperature range
Environment Characteristics	Temperature range	-55°C~+125°C
	TCR
	TCR	±100×10-6/°C
	Temperature shock	ΔR≤±3%R
		ΔR≤±3%R
	Collision (390m/S2, 4000 times)	ΔR≤±1%R
	Collision (390m/S2, 4000 times)	ΔR≤±1%R
	Vibration (10-500HZ, 0.75mm, 6h)
	Vibration (10-500HZ, 0.75mm, 6h)	ΔR≤±1%R, Electrical break≤100μS
	Operation lowtemperature (-55°C,40h)	ΔR≤±3%R,starting torque≤10mN.m

	Climate category (IEC68-2-2)
	Climate category (IEC68-2-2)	ΔR≤± (5%R+0.1Ω),Insulation Resistance≥100MΩ
	Electrical endurance (0.5W, 1000h)
	Electrical endurance (0.5W, 1000h)	ΔR≤± 3%R
	Rotational life (10000 cycles)
	Rotational life (10000 cycles)	ΔR≤±3%R, peak noise ≤ 500Ω,starting torque≤10mN.m
	Steady damp heat (IEC68-2-3, Ca, 96h)
	Steady damp heat (IEC68-2-3, Ca, 96h)	ΔR≤± 3%R, Insulation Resistance≥100MΩ,starting torque ≤20mN.m
Physical Characteristics	Total mechanical travel	360°
Physical Characteristics	Strating torque	≤5mN.m

Advantage of choosing our company and products:

Sichuan qixing electronic co. ltd. is a technical factory of mainly manufacturing and develop high power resistor,wire-wound potentiometer,metal glass glaze potentiometer,carbon film potentiometer,precision parts and AC power noise filter.
The established maxim of our company is technical innovation, keeping improvement and meet customer demands.
Rich and varied goods is your selection guide. High quality is absolutely the credibility of the guarantee. Reasonable price is your final choice.
Our products is also used in the field of the military industry .Our factory are continuing to offer a great deal of qualified goods in the field of the military industry .
