Air cooled fin condenser
- QINGDAO
- T/T
You May Like
Product Details
| Place of Origin | Shandong, China | Brand Name | ONLYKEM | |
| Model Number | FN-15 | Type | Condenser | |
| Application | Refrigeration Parts | Certification | CE |
Product Description
Air cooled fin condenser
Air condenser Parameter Introduce
1. Installing of refrigerator condenser is not confined by area ,it only needs small area
2. Entire installation,beautiful outlook design ,protect well ,can avoid collision damage
3. Condensers have double arrange ,avoid heat loss during the air transform
4. The units have good protect system inside ,good for reducing maintance
5. Use axial fan motor ,low noise ,power lose and large in air flowing
6. Large power of compressors driver quantity of cold
7. Well construction ,convenient packing and transport
We can design bigger one depends on your request. we will supply you drawing for confirmation.
Condenser parameter:
Model |
Area |
Row*line | Motor | Nozzle | Size | GW | |||
Dia. | Air-volume | power | in | out | L*W*H | ||||
M2 | n | Φmm | M3/h | W | Φmm | Φmm | mm | kg | |
FN1-2B | 2.1 | 2*4 | 200 | 500 | 16 | 10 | 10 | 340*120*255 | 2.5 |
FN1-3B | 3.4 | 3*4 | 200 | 500 | 16 | 10 | 10 | 340*120*255 | 3 |
FN1-4B | 4.0 | 3*5 | 250 | 800 | 40 | 10 | 10 | 400*130*300 | 3.5 |
FN1-6B | 6.0 | 3*7 | 300 | 1250 | 60 | 10 | 10 | 410*155*360 | 4 |
FN1-8B | 8 | 4*7 | 300 | 1250 | 60 | 10 | 10 | 410*195*360 | 6 |
FN1-12B | 12 | 4*8 | 350 | 1800 | 90 | 16 | 12 | 410*220*440 | 9 |
FN1-15B | 15 | 4*9 | 350 | 1800 | 90 | 16 | 12 | 470*220*500 | 11 |
FN1-18B | 18 | 4*10 | 400 | 3000 | 120 | 16 | 12 | 470*220*550 | 12 |
FN1-22B | 22 | 4*8 | 400 | 2*1800 | 2*90 | 19 | 16 | 570*230*550 | 14 |
FN2-28B | 28 | 4*8 | 350 | 2*1800 | 2*90 | 19 | 16 | 650*270*510 | 16 |
FN2-33B | 33 | 4*9 | 400 | 2*3000 | 2*120 | 19 | 16 | 880*230*600 | 22 |
FN2-41B | 41 | 4*12 | 400 | 2*3000 | 2*120 | 19 | 16 | 920*220*540 | 17 |
FN2-49B | 49 | 4*14 | 400 | 2*3000 | 2*120 | 19 | 16 | 1160*230*660 | 25 |
FN2-55B | 55 | 4*14 | 400 | 2*3000 | 2*120 | 22 | 19 | 1010*230*660 | 26 |
FN2-60B | 60 | 4*14 | 400 | 2*3000 | 2*120 | 22 | 29 | 1010*270*660 | 33 |
FN4-70B | 70 | 4*18 | 350 | 4*1800 | 4*90 | 22 | 19 | 1140*230*850 | 33 |
FN4-80B | 80 | 4*21 | 350 | 4*1800 | 4*90 | 25 | 19 | 1140*230*950 | 40 |
FN4-100B | 100 | 4*24 | 400 | 4*3000 | 4*120 | 30 | 22 | 1140*230*1150 | 49 |
FN4-120B | 120 | 4*24 | 400 | 4*3000 | 4*120 | 30 | 22 | 1140*250*1160 | 53 |
FN4-140B | 140 | 5*24 | 450 | 4*4500 | 4*250 | 30 | 22 | 1170*250*1260 | 66 |
FN4-150B | 150 | 5*24 | 450 | 4*4500 | 4*250 | 30 | 22 | 1270*270*1260 | 74 |
FN4-180B | 180 | 6*24 | 500 | 4*6000 | 4*250 | 30 | 22 | 1470*300*1260 | 87 |
Onlykem Technology Co.,Ltd. is a new company just founded in 2009, but we are not a newcomer to refrigeration insustry, we have more than 10 years working experience in refrigeration field, we are young, energetic, innovative and confident!
We don't want to be a sucessful businessman, we would like to be skilled craftsman, The idea of making a perfect machine is always fascinating for us. Now our products are in South America, Our stable quality, competitive price and immediate service help us possess more and more customers.
In future, we believe that you can enjoy more fresh life with our refrigeration unit, we would like to achieve this dream with your together and help more and more people enjoy quality life.
