China Citrus Fruits and Banana Ripening Rooms with condensing uni
1.Temperature: about +20'C
2.Size: Customization.
3.ISO9001,CE,Turnkey projects.
4.Components: Condensing unit, evaporator, PU panel, cold room door
5.Functions: freshkeeping storage for food refrigeration, industry refrigeration, fresh preservation of fruits and vegetables, large supermarket, cold storage of hotels ect.
6.Compressor brand: Bitzer,Emerson copeland,Danfoss,Tecumseh4.ISO9001,CE,Turnkey projects.
7.Easy installation,economical and energy saving,environmental friendly,reliable quality,professional service
8.Excellent quality ,Dependable performance,Easy installation,Economical and Energy saving,Environmental friendly,Reliable quality,Professional service.
1.Condensing unit for China Citrus Fruits and Banana Ripening Rooms with condensing unit :
Bitzer,Emerson copeland,Danfoss,Tecumseh
Air Cooled Type |
Conderser Fan |
Water Cooled Type |
water cooled condenser and cooling tower |
Evaporative Cooled Type |
Evaporative Condenser |
2.High efficiency air-cooler:
Customized air-cooler.
Water defrosting or electrical deforesting evaporator defrost faster, save operating costs.
3.Insulation Panel:
1.Panel Thickness Available: 50mm, 75mm, 100mm, 120mm, 150mm, 180mm and 200mm
2. Panel Width Available: 970mm (standard size) and 1000mm
3. Panel Length Available:2000mm-12000mm
4.Regular Steel Sheet Color Code: RAL 9002(Grey White)
5.PU Material Origin:Germany, Japan or Korea
6.PU Density: 42 +/- 2 kg/m3
7.Heat Transfer Coefficient: =0.022 W/M2*K
8.Pressure: =0.10Mpa
9.Cubic Area Change: =1% (-30 C-100 C/96h)
10.Fire Rating: B2
11. Surface of Panels: plating 0.4mm, 0.5mm or 0.6mm pre-painted white hot galvanized steel sheets or stainless steel sheets and PVC protected films.
12. Panel Connection:cam lock type, use hexagonal key to assemble and disassemble.
Thickness of cold room panel |
Application temperature |
50mm |
Temperature 5°C or above |
75mm |
Temperature -5°C or above |
100mm |
Temperature -25°C or above |
150mm |
Temperature -45°C or above |
200mm |
Temperature -55°C or above |
4.Doors :
Cold Room Door Type: Hinged Door, Sliding (revolving door) Door, Swing Door
Cold Room Door Surface Material: Coloring Steel, Stainless Steel
Cold Room Door Feature:
Brand New, Accessories with Excellent Quality
Custom-made, Good Airtight Performance, Lightweight
5.Other accessories: world-famous brands, like Danfoss, Castle, Every Control, Siemens, LG
Applications:
Food (meat, vegetable, fruit, dairy, drink), Medicine, Chemical, Electronics,etc.
Storage products |
Storage temperature approach |
Vegetables, Fruit chlling storage |
-5~5 'C |
Drink, Beer chilling storage |
2~8'C |
Meat, Fish freezing storage |
-18~-25'C |
Meat, Fish blast freezer |
-35~-40'C |
Medicine chilling storage |
2-8'C |
Medicne freezing storage |
-20'C |
Our advantages:
The Proof of Quality:
Now we have customers in different countries and places, such as Canada, USA, Australia, New Zealand, Singapore, Argentina, Middle- East, Africa…
The Guarantee of Quality:
Reasonable design, Professional technicians, Skilled and steady production workers, Full-scale Equipments, Strict QA & QC system…
Custom-made Design:
We supply our design drawing according to customer practical situation.
Technique Support:
Walk in cold room: we supply our diagrammatic drawing, feel easier for installation.
Cold storage warehouse: We have nearly 20 professional engineers who can go aboard to supply technology support and direction, until turn key for our customers.
International Trade Operation:
We have concentrated on international trade of cold storage room line for more than 10 years, accumulated various experience from different customers of different countries. So we can update our operation in time according to our customers and new rules. It is helpful to clear custom and save cost and time for our customers.
Customer case:
It is portable cold room with high insulating PU Panel, reliable quality compressor and unit cooler, and other accessories. the size depends on your stock tons and temperature.
We can do customized dimension according to customers'requirements. We have access to all the leading Cold Room refrigerators brands and can offer independent advice, and recommend the right equipment to meet your business requirements.
To make a fast and detailed quotation for you,we would like you to answer some questions about this product as following:
1. what is your cold room used for?
2. what is your required room temperature?
3. what is the cold room dimension or how much food or other products will be put inside?
4. what is your voltage, phase and hertz?
5. what is your refrigerant?
Before shipment, our engineer has a whole installation in advance. In this way, you needn’t worry our cold room can’t work when you install.
