supermarket store cold room for food in South America

Specifications

1.Temperature: -45~ +20'C .
supermarket store cold room for food in South America
3.Easy to use and maintenance.
4. CE

supermarket store cold room for food in South America

Feature of Store Cold room
1.Temperature: -45~ +20'C
2.Size: Customization.
3.ISO9001,CE,Turnkey projects.
4.Components: Condensing unit, evaporator, PU panel, cold room door
5.Functions: freshkeeping storage for food refrigeration, industry refrigeration, fresh preservation of fruits and vegetables, large supermarket, cold storage of hotels ect.
6.Compressor brand: Bitzer,Emerson copeland,Danfoss,Tecumseh4.ISO9001,CE,Turnkey projects.

7.Easy installation,economical and energy saving,environmental friendly,reliable quality,professional service
8.Excellent quality ,Dependable performance,Easy installation,Economical and Energy saving,Environmental friendly,Reliable quality,Professional service.



Size: Customization.
Classification	Small	Middle	Large
Volume Range	<500m3	500~10000m3	>10000m3



Components for supermarket store cold room for food in South America :

1.Condensing unit for store cold room:

   Bitzer,Emerson copeland,Danfoss,Tecumseh

Air Cooled Type	Conderser Fan
Water Cooled Type	water cooled condenser and cooling tower
Evaporative Cooled Type	Evaporative Condenser









2.High efficiency air-cooler of supermarket store cold room for food in South America :



  Customized air-cooler.



  Water defrosting or electrical deforesting evaporator defrost faster, save operating costs.

3.Insulation Panel of supermarket store cold room for food in South America :

     Use 100%polyurethane insulation panel,density about 38~46kg/m3,with gasket,with flame retardant,panel thickness:100mm~200mm, standard width of panel is 960mm



Polyurethane insulation board design for cold room, the main steel structure to facilitate construction. Portable sliding doors, and out of cold storage more convenient, easy to operate.





Thickness of cold room panel	Application temperature
50mm	Temperature 5°C or above
75mm	Temperature -5°C or above
100mm	Temperature -25°C or above
150mm	Temperature -45°C or above
200mm	Temperature -55°C or above







4.Doors of supermarket store cold room for food in South America :

1.Swing door and sliding door for choice.

2.Swing door:manual opened,automatic,etc.

3.Door board made with special pressing technology PU material.

4.Door frame:color steel or stainless steel.

5.Surface material:color steel or stainless steel with protecting film.













5.Other accessories: world-famous brands, like Danfoss, Castle, Every Control, Siemens, LG







Applications of supermarket store cold room for food in South America :

 Food (meat, vegetable, fruit, dairy, drink), Medicine, Chemical, Electronics,etc.

Storage products	Storage temperature approach
Vegetables, Fruit chlling storage	-5~5 'C
Drink, Beer chilling storage	2~8'C
Meat, Fish freezing storage	-18~-25'C
Meat, Fish blast freezer	-35~-40'C
Medicine chilling storage	2-8'C
Medicne freezing storage	-20'C



Our advantages:
1.ORGREN Cold room have abundant experience in trading and installation abroad for many years..
2.ORGREN can provide the most reasonable configuration and price of cold room for customers.



Customer case:





It is portable cold room with high insulating PU Panel, reliable quality compressor and unit cooler, and other accessories. the size depends on your stock tons and temperature.





We can do customized dimension according to customers'requirements. We have access to all the leading Cold Room refrigerators brands and can offer independent advice, and recommend the right equipment to meet your business requirements.















To make a fast and detailed quotation for you,we would like you to answer some questions about this product as following:





1. what is your cold room used for?



2. what is your required room temperature?



3. what is the cold room dimension or how much food or otherproducts will be put inside?

4. what is your voltage, phase and hertz?

5. what is your refrigerant?
