Help CenterBONESN W206 Potentiometer Single-turn Potentiometer
Related Products
-
BONESN W208-1AN Potentiometer Single-turn Potentiometer Glass Glaze TrimpotNegotiableMOQ: 100 Pieces -
BONESN W208-2AL Potentiometer Single-turn Potentiometer Glass Glaze TrimpotNegotiableMOQ: 100 Pieces
-
BONESN W208-2AN Potentiometer Single-turn Potentiometer Glass Glaze TrimpotNegotiableMOQ: 100 Pieces
-
BONESN W208-1AL Potentiometer Single-turn Potentiometer Glass Glaze TrimpotNegotiableMOQ: 100 Pieces
-
BONESN W208-2AS Potentiometer Single-turn Potentiometer Glass Glaze TrimpotNegotiableMOQ: 100 Pieces
Specifications
1. W206 Trimmer Potentiometer,Single-turn2. ROHS certification
3. ISO9001:2008
4. reasonable price
5.100-1M ohm
Details of Products:
| Electrical Characteristics | Range of nominal resistance | 10Ω~1MΩ | ||||
| Resistance tolerance | ±20% | |||||
| Terminal resistance | ≤±1%R or 10Ω | |||||
| Contact resistance variation (CRV) | ≤±3%R | |||||
| Insulation resistance | ≥ 500MΩ (100V AC) | |||||
| Withstand voltage | 250V (DC or AC peak value) | |||||
| Effective electrical travel | ≥200° | |||||
| Environment Characteristics | Rated power | 0.25W ( 300V max) | ||||
| Temperature range | ||||||
| -55°C~+125°C | ||||||
| TCR | ±250×10-6/°C | |||||
| Collision (390m/S2, 4000 times) | ΔR≤±1%R | |||||
| Vibration (10-500HZ, 0.75mm, 6h) | ΔR≤±1%R, ΔUab/Uac≤±2%R, Electrical break≤100μS | |||||
| Temperature variation (-55°C/30min, +125°C/30min, 5 cycles) | ΔR≤±2%R,ΔUab/Uac≤±2%R | |||||
| Climate category (IEC68-2-2) | ||||||
| ΔR≤± (10%R+0.1Ω), Insulation Resistance≥100MΩ | ||||||
| Electrical endurance (0.25W, 1000h) | ΔR≤± (5%R+0.1Ω) | |||||
| Mechanical endurance (200 cycles) | ΔR≤± (20%R+0.5Ω), | |||||
| Steady damp heat (IEC68-2-3, Ca, 96h) | ΔR≤± (10%R+0.1Ω), Insulation Resistance≥100MΩ | |||||
| Physical Characteristics | Total mechanical travel | 240° | ||||
| Starting torque | ||||||
| ≤20mN.m | ||||||
| Stopper torque | ||||||
| ≥F50mN.m | ||||||
| Soldering Conditions | ||||||
| 240°C-260°C(5 seconds) | ||||||
Related Potentiometer:
Some Main Products:
Function of potentiometer:
A potentiometer is a manually adjustable electrical resistor that uses three terminals. It is a simple electro-mechanical transducer. It converts rotary or linear motion from the operator into a change of resistance, and this change is used to control the levels of output. It is sometimes known as POTS.Potentiometer is an adjustable electronic components,which plays main roles in the circuit on the following several aspects
1.As a voltage divider:Potentiometer is a continuously adjustable resistor. When potetiometer’s stem or sliding handle move on the resistor body, the output of the potentiometer can be obtained output of voltage with certain related to the potentiometer applied voltage and movable arm or travel .
2.As a variable resistor :When potentiometer is used as a rheostat, it should be taken into two end devices.Thus within the limited travel range of potentiometer,which can be gotten smooth, continuously changable resistance value.
3.As the current controller :Potentiometer is used as the current controller, one of the designate current output must be sliding contact terminal.
4.Application of potentiometers
•Linear displacement measurement
•Rotary displacement measurement
•Volume control
•Brightness control
•Liquid level measurements using floats
Some parts of our certificates
Advantage of choosing our company and products:
- Sichuan qixing electronic co. ltd. is a technical factory of mainly manufacturing and develop high power resistor,wire-wound potentiometer,metal glass glaze potentiometer,carbon film potentiometer,precision parts and AC power noise filter.
- The established maxim of our company is technical innovation, keeping improvement and meet customer demands.
- Rich and varied goods is your selection guide. High quality is absolutely the credibility of the guarantee. Reasonable price is your final choice.
