3296 Trimmer Multi-turns Joystick Potentiometer

Sichuan Qixing Electronics Co., Ltd.
3296 Trimmer Multi-turns Joystick Potentiometer thumbnail-1
3296 Trimmer Multi-turns Joystick Potentiometer photo-1
US$ 0.05 - 0.15 MOQ: 100 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Sichuan, China
Brand Name:
BONENS
Model Number:
3296W with long worm
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzheng
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Sichuan, China
Brand Name BONENS
Model Number 3296W with long worm
Type Trimming Potentiometer
Technology Other, Glass Glaze
Resistance 10Ω~5MΩ
Resistance Tolerance ±10%
Rated Power 0.5W
Max. Operating Voltage 640V
Operating Temperature -55℃~+125℃

Specifications

1.8 years producing experience
2.ISO9001,TUV,ROHS certificate
3. joystick potentiometer
4.OEM service
5.free sample

Some parts of our certificates

3296 Trimmer Multi-turns joystick potentiometer

Advantage of choosing our company and products:

1. Sichuan qixing electronic co. ltd. is a technical factory of mainly manufacturing and develop high power resistor,wire-wound potentiometer,metal glass glaze potentiometer,carbon film potentiometer,precision parts and AC power noise filter.

2. The established maxim of our company is technical innovation, keeping improvement and meet customer demands.

3. Rich and varied goods is your selection guide. High quality is absolutely the credibility of the guarantee. Reasonable price is your final choice.

4. Our products is also used in the field of the military industry .Our factory are continuing to offer a great deal of qualified goods in the field of the military industry .

















Electrical CharacteristicsRange of nominal resistance10Ω~5MΩ
Resistance tolerance
±10%
Terminal resistance
≤±1%R or 2Ω
Contact resistance variation (CRV)
≤±1%R or 3Ω
Insulation resistance
≥ 1GΩ (100V AC)
Withstand voltage
640V (DC or AC peak value)
Effective electrical travel
≥70% of  mechanical travel



Environment Characteristics

Rated power0.25W ( 300V max)
Temperature range
-55°C~+125°C
TCR
±250×10-6/°C
Collision (390m/S2, 4000 times)
ΔR≤±1%R
Vibration (10-500HZ, 0.75mm, 6h)
ΔR≤±1%R, ΔUab/Uac≤±2%R, Electrical break≤100μS
Temperature variation (-55°C/30min,
 +125°C/30min, 5 cycles)		ΔR≤±2%R,
 ΔUab/Uac≤±2%R
Climate category (IEC68-2-2)
ΔR≤± (5%R+0.1Ω),Insulation Resistance≥100MΩ
Electrical endurance (0.5W, 1000h)
ΔR≤± (5%R+0.1Ω),CRV≤±3%R or 5Ω
Mechanical endurance (200 cycles)
ΔR≤± (10%R+0.5Ω), CRV≤±3%R or 5Ω
Steady damp heat (IEC68-2-3, Ca, 96h)
ΔR≤± (5%R+0.1Ω), Insulation Resistance≥100MΩ

Physical CharacteristicsTotal mechanical travel12±2 lap
Starting torque
≤25mN.m
Standard package
 50 pcs /tube(3296W,3296Y)

40 pcs /tube(3296X,3296Z,3296P)
