Product Details
| Condition | New | Application | Apparel, Beverage, Chemical, Commodity, Food, Other, Textiles, Apparel, Beverage, Chemical, Commodity, Food, Machinery & Hardware, Textiles | |
| Packaging Type | Other, Paperboard carton package | Packaging Material | Paper | |
| Automatic Grade | Automatic | Driven Type | Mechanical | |
| Voltage | 380V 50HZ | Power | 35KW | |
| Place of Origin | Henan, China | Brand Name | MIRACLE | |
| Model Number | Production Line | Dimension(L*W*H) | 1800*1000*2200MM | |
| Weight | 10MT-28MT | Certification | CE Certification | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Top sale in 2016 corrugated paperboard with E flute handling machine price
- The Corrugated Cardboard Production Line is also called corrugated line, It can be used for Corrugated Cardboard Box Factories.
- It is the most important equipment in packaging industry. It includes some important parts, Wet-Section Equipment, Dry-Section Equipment, and production management system according to the different technique and process flow.
Introduction of Top sale in 2016 corrugated paperboard with E flute handling machine
- Single layer, 3 ply, 5 ply, 7ply corrugated fiberboard production plant are available for us.
- Flute type will decide the corrugated cardboard strength, different fluted board application need different flute combination. Pls choose flute no. according to ur request.
- Production Flow: Raw material--Wet Section(Forming corrugated system)--Dry Section(Former and dryer for corrugated cardboard)--NC slitter scorer--Helical cross cutter--Stacker.
Top sale in 2016 corrugated paperboard with E flute handling machine
Flute Type | Flute Height(MM) | Qty/300mm length | Remarks |
A | 4.6-4.9 | 34 +/-2 | Usually for lining |
C | 3.6-3.9 | 38 +/-2 | Usually for lining |
BC | 3.2-3.3 | 44 +/-2 |
|
B | 2.6-2.9 | 50 +/-2 | Usually for Printing |
D | 2.0-2.2 | 78 +/-2 |
|
E | 1.5-1.8 | 88 +/-2 | Usually used for color printing |
| 1.1-1.5 | 98 +/-2 | |
F | 0.8-1.0 | 128 +/-2 |
1.Which layers is most popular for application?
There are four types:single layer, 3 ply, 5 ply, 7 ply corrugated cardboard production line. Popular one is 5 layers.
2.How could we choose plant?
Pls inform us ur request, applied market, warehouse dimension and plant budget, our engineer, sales person will send u the suggestion and proposal.
3.Could we visit your factory and customer site?
Yes, we sincerely welcome you to come to our factory for further discussion.
Miracle machinery integrate service system
a. Pre sales-----Consulting, Designing, Equipment selection, Technology Discussion.
b. During sales-----Programs and drawings confirmed, Installation guide, Equipment debugging.
c. After sales-----Testing acceptance, Customer training, Technical exchanges, Regular visits.
We promise:
Corrugated cardboard production line for sale and all the products purchased in our company are guaranteed to keep in good repair for one year. If quality problems happen in guarantee period, our company will maintain for free. Additionally, our company provides technical support and fittings for life.
Pls contact us to get more details and proposal about Top sale in 2016 corrugated paperboard with E flute handling machine price
