The Third Generation Wood Pallet Making Machine From Waste Wood Hot Sale
The third generation wood pallet making machine from waste wood hot sale
Introduction of The third generation wood pallet making machine from waste wood
The third generation wood pallet making machine from waste wood hot sale is used to make the wood pallet which is used into the transportation. It adopts sawdust or wood chips as raw material, hydraulically pressed by high temperature up and down into a pallet.
The raw material under the moisture 8-10%, mixed with a special glue for wood waste, heating and pressing by high pressure around 800t-1200t, and finally shape into a solid wooden pallet. The final pallet density is around 800-850kg/cbm. The whole wood pallet production line can be operated automatically. We can supply auto- feeding, auto- drying, auto- gluing and mixed material auto-feeding press machine, and finally auto-discharging. From material to the final products, the whole plant needs at most 5 worker.
The raw material for the third generation wood pallet making machine from waste wood
Sawdust, wood shavings, wood chips, waste wood, used pallet, cotton stalk and so on.
The advantages of The third generation wood pallet making machine from waste wood
- Water proofs, insect prevention, and protection against termites.
- Eco-friendly (E2) and 100% degradable.
- Pallet can be used in export package, free fumigation & free quarantine, do not need any test before export.
- The reasonable design makes our products have the advantage of saving storage space, light weight and elegant appearance.
- High loading capacity, strong and durable physical properties, and long working life.
- Formed by one time molding, without any metal parts.
- Reasonable design of the structure, high performance.
- Strong bearing capacity, no deformation and can be reused.
- Wooden pallet can be forked from four directions, use it easily.
- It can be store in bulk, save room, easy to be transported.
Process of the third generation wood pallet making machine from waste wood hot sale
1.Crushing--Crush wood branches, biomass, used pallets, wood logs, waste wood etc into powder, wood shavings or wood chips;
2. Drying---Dry the raw materials into certain moisture as 10%;
3. Glue Mixing---Mix materials with glue water;
4. Pressing---Press materials into pallet shape as your required size.
Parameters of wood pallet making machine from waste wood
Model | MRC-1000T | MRC-1200T |
Working pressure | 1000t | 1200t |
Density of pallet products | 800-850kg/m³ | 900kg/m³ |
Capacity | 120-150 pcs/day | 120-150 pcs/day |
Oil tank qty | 290/4pcs | 320/4pcs |
Increased pressure time | 35s | 35s |
Shape cycle | 450s | 450s |
Dimension | 2300*1300*4300mm | 2300*1300*4300mm |
Weight | 9800kg | 12900kg |
Photos of hydraulic type hot press wooden pallet machine from waste wood
We provide the integrated customer service system
- Pre sales: Consulting, Designing, Equipment selection, Technology Discussion.
- During sales: programs and drawings confirmed, installation guide, equipment debugging.
- After sales: Testing acceptance, customer training, technical exchanges, regular visits.
Guarantee and maintance of The third generation wood pallet making machine from waste wood hot sale
- Malfunctions which are caused by machine-self and quality will be responsible for our manufacturer.
- Other malfunctions which are caused by operation mistakes, man-made problems will be responsible for clients-self.
- All products purchased in our company are guaranteed to keep in good repair for one year. If quality problems happen in guarantee period, our company will maintain for free. Additionally, our company provides technical support and fittings for life. After-sales service isn't restricted by time and we will solve your problems in time.
- If you are caught in some problems when using our products, welcome to contact us at any time.
1. What is the moisture of raw material for making wooden pallet?
8%-10% is better for the third generation wood pallet making machine from waste wood to process.
2. How to pack the wood pallet press machine when deliver plant?
The third generation wood pallet making machine from waste wood hot sale can be disassembled, the height is around 2.75m after disassembling, We will use the 40 feet top open container for delivery.
3. Need glue or not for wood pallet machine?
Yes. Need glue. For glue using level and spcs, pls contact our sales director by mail or mobile phone.
