Introduce of reverse osmosis water treatment machine
Reverse osmosis is a membrane separation technology which depend on one select Gongli (half through) membrane pressure as the driving force , when the pressure of the system is bigger than the osmotic pressure of the feed aqueous solution, water moleculesconstantlythrough the membrane, through the production conduit into the center tube, thenthe outflow of impurities in the water at one end, such as ions, organic matter, bacteria, viruses, etc., are retained in the water side of the membrane, and then the water side ofthe dense water outflow, so as to achieve the separationpurification purposes.
Reverse osmosis distilled water machine
Pretreatment system
Generally include the original pumps, dosing device, the quartz sand filter, activated carbon filter, precision filter. Its main role is to reduce the raw water pollution index, and residual chlorine and other impurities, to achieve the reverse osmosis waterrequirements. The pretreatment system’s device configuration should be based on thespecific circumstances of the original water.
Reverse osmosis unit
Including multi-level high-pressure pump, the composition of the reverse osmosis membrane element, membrane shell (pressure vessels), such as a stent. Its main role isto remove impurities in the water effluent to meet the requirements.
Post-processing system
Is the configuration in the case of reverse osmosis can not meet the water requirementsincrease. Including the anion bed, sun bed, mixed bed, sterilization, ultrafiltration, EDI, etc. where one or multiple devices. Post-processing to better improve the system be able to reverse osmosis water quality, so as to meet the requirements.
Cleaning system
Cleaning tank, cleaning pump, precision filter components. Cleaning to restore the effectiveness of reverse osmosis system can not meet the requirements of contaminatedwater indicators, the need for reverse osmosis.
Electrical control system
Is used to control the normal operation of the entire reverse osmosis system. Includingthe instrument panel, control panel, all kinds of electrical protection, electrical control cabinet.
Main Parameters of RO Water Purification Plant
| Name | Material Origin |
Type |
Quantity |
| The original pump | Lingxiao pump |
BLC70/0.55 |
1SET |
| Mechanical filter
|
SUS304
|
Dia.300×1200×δ2 |
1SET |
| Mechanical filte r
|
SUS304
|
Dia.300×1200×δ2.0 |
1SET |
| Precision filter |
SUS304
|
Dia.200×500×δ1.5 |
1SET |
RO unit |
|||
| Membrane shell | SUS304 |
4040 |
4SETS |
membrane |
Hydranautics |
ESPA-4040 |
4SETS |
| Multistage Pump | Made in china |
CDL2-180 |
1SET |
| Conductivity Monitor | Made in china |
1SET |
|
| Flowmeter | Suzhou |
1T |
2SETS |
| Solenoid valve | Made in china |
DF15 |
1SET |
| Stainless steel chassis | SUS304 |
1SET |
it will back in export wooden case ,the total packing volume will be 8CBM
Export to Haiti 2014 Sep
