CE Approved Portable Stroboscope used for gravure printing
Type : Portable digital rechargeable
Model No. : DT 325E
The DT-325E LED hand-held stroboscope is our latest new energy products, it uses America CREE high power LED lamp, has the characteristics of wide measurement range, high brightness, light weight, long life time, can be used at any time, any place. With convenient operation, the built-in lithium battery, single use time is more than 12 hours. This stroboscope used to measure the motion of the object, when the strobe flash speed and high-speed moving objects in synchronous speed, we see a relatively static state, the principle that we can clearly observe some mechanical work gear, movement of all kinds of rotor.
This Stroboscope can be widely used in packaging and printing industry, printing, die cutting, punching quality detection, folding; used for speed measurement of spindle spinning machine, textile industry and winding machine for mechanical manufacturing industry; also can be used for aircraft manufacturing, automobile manufacturing, cable manufacturing, mining, shipbuilding, steel, chemical, optical, medical and other industries.
Setting accuracy (vibration): 0.01%±1 digit(25°C)
Set the resolution (vibration): 60 .0~12,000FPM 0.1 FPM
12000.1~120,000FPM 1 FPM
1~200HZ 0.01 HZ
200.1~2000 0.012 HZ
LED Spec.: American CREE 10W LED light, Life time is 3~5 years.
Battery:DC 10.8V2000mA
Power:Above 15W
Dimension:208mm X 70mm X 60 mm
Net weight: 380g
Main features
Two units of measure-FPM(flashes per minute)and Hz
Wide flash range-60 to 120,000FPM
Multiply or Divide by 2
Phase Shift function”+“or “-“ to “+3°”,“-3°”
Adjustable flash duration-(RATIO)Time can change for 0.1° each tine as in the range of 0.1°-2.5°
External input/output port-Synchronization of flash rate with external pulse, and output the pulse signal with flash rate
