DT316P Rechargeable Stroboscope
Technique parameters
Type: |
DT-316P |
Power supply: |
AC220V |
Power: |
≤45W |
Internal Trigger frequency range |
1-18000 times/min |
External Trigger frequency range: |
1-30000 times/min |
Single Working Hours: |
function key set no limited |
Environmental illumination: |
< 10000 Lux |
External trigger signal range |
5 ~ 12V pulse signal |
Packaging specifications: |
31*25.5*15cm |
Packaging
| Single item |
| 30X24X12 cm |
| 2.5 KG |
| Each in separate box, 5 boxes in one big outer carton. |
Portable digital plug-in stroboscope DT316P
1.Usage: Still images observation overprint
2.Power: AC 220V+ / -10%
3. Type: Portable and Plug-in. (Connect with power supply directly)
Introduction:
This Stroboscope can be widely used in packaging and printing industry, printing, die cutting, punching quality detection, folding;
used for speed measurement of spindle spinning machine, textile industry and winding machine for mechanical manufacturing industry;
also can be used for aircraft manufacturing, automobile manufacturing, cable manufacturing, mining, shipbuilding, steel, chemical, optical, medical and other industries.
1.Operating voltage: DT316 P: AC220V
2.Total labor rate: DT316 Series Maximum power is less than 45W
3.The trigger frequency range: 60 rpm / MIN ~ 18000 rpm / MIN
4. The external trigger frequency range: 1 rpm/ MIN ~ 99999 rpm / MIN
5. The ambient light: less than 10,000 lux
6. Using the German Hyman original lamp life 1 * 108
7. External trigger signal range: 5V ~ 12V pulse signal (high level trigger)
8. Dimensions: DT316 Series 250 * 120 * 120 (82)
This Stroboscope can be widely used in packaging and printing industry, printing, die cutting, punching quality detection, folding;
used for speed measurement of spindle spinning machine, textile industry and winding machine for mechanical manufacturing industry;
also can be used for aircraft manufacturing, automobile manufacturing, cable manufacturing, mining, shipbuilding, steel, chemical, optical, medical and other industries.
1. In order to protect the strobe tube not damaged by the power impact, make sure each powering on interval over 10 seconds.
2. Pls , remember to recharging again after usage every time , make sure the usage for the next time.
Product Use
