Home > Manufacturing & Processing Machinery > Textile Machinery & Parts > Knitting Machine > Plain Socks Knitting Machine
Plain Socks Knitting Machine
US$ 3,000 - 3,200
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Plain Knitting Machine
Production Capacity:
250Pairs/Day
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Socks Knitting Machine in Zhuji CityUS$ 3,000 - 3,200MOQ: 1 Set -
Centrifugal Dewatering MachineNegotiableMOQ: 1 Set
-
2Seats Electric Golf Cart, Battery Golf Cart, Batterie Voiturette de GolfNegotiableMOQ: 1 Set
-
EG204AK 4 Seats Golf Cart, Carrito de Golf, GolfwagenNegotiableMOQ: 1 Set
-
Lead Acid Battery Electric BikeNegotiableMOQ: 1 Set
Condition
New
Type
Plain Knitting Machine
Production Capacity
250Pairs/Day
Place of Origin
Zhejiang, China
Brand Name
FENGZU
Model Number
301P
Voltage
220V/380V
Power(W)
1.9KW
Weight
350KG
Dimension(L*W*H)
111*77*176CM
Warranty
1 Year
After-sales Service Provided
Engineers available to service machinery overseas
Product Description
Plain Socks Knitting Machine
| Specifications: | |||
| Cylinder Diameter | 3.5"/3.75'' | ||
| Needle Number | 72N-240N | ||
| Maximum Speed | 330RPM | ||
| Driving Control | Sever Motor | ||
| Voltage | 220V/380V | ||
| Main Motor | 1.1KW | ||
| Fan | ≥1.1KW(Selection) | ||
| Control Box | 0.8KW | ||
| Site Area | 150*120*240cm | ||
| Net Weight | 300KG | ||
| Gross Weight | 350KG | ||
| Package Size | 111*77*176cm | ||
| Main Feature and Function | |||||||||
| 1. It has capability of weaving 1 main color and 5 secondary colors for each line. (6F) | |||||||||
| 2. Each of the socks can be weaved 15-18 colors. | |||||||||
| 3. Adapted with fully computerized control system with no drum, the main motor adopt with the 1.0RW servo motor. | |||||||||
| 4. All functions by the electronic valve control the elastic, density is completed by stepper motor. | |||||||||
| 5. Adapted with the automatic lubricating oil system with high sensitivity of the protection device for disconnection and broken needle. | |||||||||
| 6. Adapted with LED screen with Chinese and English language. | |||||||||
| 7. It can keep the pattern saved in memory when the power was cut off by accident. With the USB to store many different patterns to make the machine more credible and stable. | |||||||||
| 8. Drawing system by WINDOW98/2000/XP design, the pattern making software will be given for free. | |||||||||
| 9. Text-self fault checking and automatic shut down, and the fault reasons showed on LCD screen. | |||||||||
| 10. Double down picker, reducing torque and improving production, and this type is fit to make the 3D socks. We can also supply high quality Double Screw Air Compressor to work with the Socks Knitting Machine. | |||||||||
| 11. Adapted with automatic program control of oil lubrication, after changing the cylinder, the needle number and needles' distance modified completedly by keyboard. | |||||||||
| 12. This machine adapt with the professional yarn suction mouth, to reduce the blocking of yarn suction mouth. Also this machine have the function that recycle the waste yarn to solve the blocking problem. | |||||||||
| 13. All knitting process worked with computer-controlled valve to reduce fraying, that doesn't affect the performance and increase the maintenance burden. | |||||||||
| 14. Computer-controlled box can store 2 different kinds of patterns in the same time, and it can be turned freely It can changed work freely after setting the left and right socks. | |||||||||
| 15. The computer can regulate score according to body structure to make the products more fit. | |||||||||
| 16. The machine weave plain ,rib, mesh, tuck, elastic jacquard, arcturus heel, anti-socks head, heel change the yarn, multi-level rib top, foot reinforcement, around patterned socks. | |||||||||
