Help CenterConstant Voltage Pressure Sensor
US$ 15 - 26
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Shaanxi, China
Brand Name:
HT
Model Number:
HT15V
Payment & Shipping
Payment Methods:
Port of Shipment:
XI'AN
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Constant Voltage Pressure SensorUS$ 15 - 19MOQ: 1 Piece -
Piezoresistive Silicon Pressure SensorUS$ 24 - 28MOQ: 1 Piece
-
Flush Diaphragm Pressure SensorUS$ 24 - 28MOQ: 1 Piece
-
Oil Filled Pressure SensorUS$ 24 - 28MOQ: 1 Piece
-
Diffused Silicon Differential Pressure SensorUS$ 32 - 40MOQ: 1 Piece
Place of Origin
Shaanxi, China
Brand Name
HT
Model Number
HT15V
Specifications
Mesurement Range:0~350KPa~60MpaIsolated pressure sensor
Constant voltage supply
Full 316L stainless steel
Description
HT15V pressure sensor, uses imported chip to manufacture, having stable &reliable performance.
Feature
Range: 0~350KPa~60Mpa
Isolated pressure sensor
Full 316LSS
Constant voltage supply
Application
Measure pressure of gases &liquids
Control instrument for liquid level
Industry process control
Medical instrument
Electrical Data
Supply: 10VDC
Input Impedance: 6KΩ~20KΩ
Output Impedance: 2.5KΩ~6KΩ
Insulation Resistance: ≥100MΩ/50VDC
Insulation Voltage: 500VAC between the case and electrical connections will not cause damage
Medium Compatible: Liquids, gases which are compatible with 316LSS
