Specifications
Battery supplywireless and distant communication transmission
Description
BPG01 wireless digital pressure gauge uses HT series piezoresistive silicon oil-filled isolation diaphragm sensor as the signal measuring element. Wireless digital communication and low power MCU is used to fulfill the remote on-line measurement of physical pressure. The signal transferred by wireless is of rapid reliability and anti-interference ability.
Features
² Wide pressure range, full stainless steel, cast aluminum structure,
² Various pressure port
² Protection: IP65
² Battery supply, wireless and distant communication transmission;
² Four digit and low-power display;
² Intrinsically safe explosion-proof type, ExiaIICT6;
Application:
² Measurement of gases and liquid that is non-corrosion to 316L stainless steel;
² Applied to petroleum, chemical industry, water supply and other wireless measurement system where there is no power supply equipment;
Specification
Measurement range |
-0.1...0~0.01...~100MPa |
Proof pressure |
≤1.5X rated pressure or 110MPa, which is less |
Pressure type |
Gauge, absolute , or sealed pressure |
Accuracy |
±0.25%(typical) ±0.5%(Max.) |
Long-term stability |
±0.1%F.S/year(typical) ±0.2%F.S/year(max.) |
Operating temperature range |
-20°C~80°C |
Storage temperature range |
-40°C~120°C |
Power supply |
Battery or common DC power supply |
Wireless communication frequency band |
430-450MHz |
Wireless communication distance |
Less than 2000m |
Battery life |
1 year |
Data transmission error rate |
≤1/100000 |
Pressure port |
M20×1.5, G1/2 or customized |
Housing material |
Stainless steel 1Cr18Ni9Ti |
Diaphragm material |
316L |
O-ring |
Fluororubber |
Insulation resistance |
100MΩ, 100VDC |
Housing protection class |
IP65 |
