Specifications
CUSTOM-MADE ,teppanyakiA, the structure
1, teppanyaki equipment from the host, the external decoration, fumes purifier and fan components.
2, equipment tops, imported steel, thickness of 20mm, material deformation, discoloration.
3, equipment for the overall design, no assembly and disassembly.
4, non-standard equipment available on-site custom stitching.
B, teppanyaki heating
1, gas heating parameters:
Gas: Gas Consumption 2.28 cubic meters per hour
LPG: Gas Consumption 0.6 kg per hour
Natural gas: gas consumption 0.8 cubic meters per hour
2, electric heating parameters:
Electric heating tube: 380V / 50HZ three-phase five-wire power 8KW
Aluminum electric heating: 380V / 50HZ three-phase five-wire power 6KW
Electric heating disk: 380V / 50HZ three-phase five-wire power 8KW
Heating test comparison
Testing the water
4 kg of water
4 kg of water
4 kg of water
4 kg of water
Category
Power Disk
Heater
Gas
LPG
Input Power
8KW
8KW
8KW
8KW
Energy
0.43
1.72
0.38 m3
0.38kg
C, countertops process:
By heat treatment, planing, grinding and other processes to make the table flat and smooth.
D, internal structure:
1, the main heating system:
Gas: 9-inch cast-iron burners, teppanyaki temperature by the gas switching system, the main heat range 500mm × 500mm.
Electric heating: heating by heating pipes, electric aluminum and electricity disk, teppanyaki temperature controlled by thermostat, the main heat range 600mm × 400mm.
2, thermal insulation systems:
Area is outside the main heat insulation system, its temperature controlled at 100 degrees, user-friendly design, to avoid customers curious touch iron table and potential safety problems.
3, fire protection systems:
Prevent flames into the exhaust pipe of the function, to eliminate potential safety hazards of fire.
4, the exhaust gas treatment system:
Inside the device so that the normal cycle of the exhaust gas is discharged.
5, double fume treatment system:
The device comes with an internal filter and oil collection drawer, to avoid a large number of oil into the pipeline, direct dripping in oil collection drawer.
