Specifications
Specifications:dn25 ppr aluminum composite pipe, pressure rating available in 1.0MPa, 1.25MPa, 1.6MPa, 2.0MPa
Specifications:
dn25 ppr aluminum composite pipe with sizes ranging from 16 to 160mm, pressure rating available in 1.0MPa, 1.25MPa, 1.6MPa, 2.0MPa and 2.5MPa
Features:
Material: random polypropylene (type 3)
Sizes: 16mm to 160mm
Pressure rating: 1.0MPa, 1.25MPa, 1.6MPa, 2.0MPa and 2.5MPa
Colors: grey, white, green or other colors on request
Connection: socket fusion joint, electro fusion joint or transition joint
Standard: ISO9001:2000
Applications: cold or hot water supply, heating system including flooring heating, wall heating and radiating system.
Advantages:
High temperature resistance: the maximum sustained working temperature is up to 70 degrees Celsius, the maximum transient temperature is up to 95 degrees Celsius
Heat preservation: low thermal conductivity which is only 1/1500 of brass pipe, and 1/250 of steel pipe
Non-toxic: no heavy metal additives, would not be covered with dirt or contaminated by bacterium
Corrosion resistant: resist chemical matters or electron chemical corrosion
Lower Installation Costs: light weight and ease of installation can reduce installation costs by as much as 50% over metal piping system
Higher Flow Capacity: smooth interior walls result in lower pressure loss and higher volume than metal pipes
Long Life: more than 50 years under normal conditions
Recycled and Environment-friendly
