YD210 Shaft Vibration Transmitter

YD210 Shaft Vibration Transmitter thumbnail-1
YD210 Shaft Vibration Transmitter photo-1
US$ 99 - 299 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Shanghai, China
Brand Name:
Ce Zhen
Model Number:
YD210
Contact Supplier Request Quote Chat Now
Shanghai Cezhen Automation Instrument Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shanghai, China
Brand Name Ce Zhen
Model Number YD210
Usage Vibration Sensor
Theory Inductance Sensor
Output Analog Sensor
YD210 Shaft Vibration Transmitter



1. Brief Introduction

The transducer is used with eddy current sensor,  mainly used for measuring axial displacement, differential expansion, shaft vibration and coating thickness of rotating machines.  Small size and easy to install, can be connected to computer, PLC, DCS and some other equipments like these.

2. Technical Parameters

a. Input signal: eddy current sensor output
b. Output signal: 4~20mA or 0-24V (can be set as users require)
c. Measurement range: 0~10mm
d. Accuracy: ±1%
e. Working voltage: DC24V, -24V power supply (can be set as users require)
f. Working temperature: -30~+50°C
g. Overall dimensions: 80×60mm
h. Overall dimensions: 51×51mm


3.Model Selection Guide


YD210—A()—B()


Measurement range A():       01:  1.0~1.0mm;

                                             02:  1.5~1.5mm;

                                             03:  2.0~2.0mm;

                                             04:  3.0~5.0mm;

                                             05:  5.0~5.0mm.

Probe diameter  B():             01: 8mm;

                                             02: 11mm;

                                             03: 16mm;

                                             04: 18mm;

                                             05: 25mm;

                                             06: 32mm;
                                             07: 40mm;


According to users requirements to design and produce many kinds of proximitors.







Product Picture

YD210 Shaft Vibration Transmitter
