Vibration Measuring Instrument Vibration Measurement Tool Accelerometer Monitor YD240 Rotation Speed Transmitter

Name: Vibration Measuring Instrument Vibration Measurement Tool Accelerometer Monitor YD240 Rotation Speed Transmitter
Brand: Ce Zhen
SKU: 101832509

Vibration Measuring Instrument Vibration Measurement Tool Accelerometer Monitor YD240 Rotation Speed Transmitter thumbnail-1

Vibration Measuring Instrument Vibration Measurement Tool Accelerometer Monitor YD240 Rotation Speed Transmitter photo-1

US$ 99 - 299 MOQ: 1 Set

Key Specifications

Get Latest Price

Place of Origin:

Shanghai, China

Brand Name:

Ce Zhen

Model Number:

YD240

Contact Supplier Request Quote Chat Now

Shanghai Cezhen Automation Instrument Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Shanghai, China

Brand Name Ce Zhen

Model Number YD240

Usage Speed Sensor

Theory Inductance Sensor

Output Analog Sensor

YD240 hall effect rotation speed transmitter

A. Overview:

1. YD240 speed transmitter can be used with many output instruments of our company and also can be connected to magnetic-electric and other speed transducers.

2. The transmitter uses the unique precision measurement method to ensure the high precision of the whole measuring range.

3. It can distinguish the vibration signal from the larger rotor vibration signal effectively.

4. Set 1-1000 pulses each turn freely. Level 2 alarm control the relay output, the alarm control mode can be flexible setting, all parameters can be set by RS485 communication.

5. Measured value convert to 4~20mA analog output.

6. Imported integrated circuits, filter components strictly; 100% the whole aging and testing to ensure high reliability of the transducer.

7. There is communication interface to connect with the computer.

8. The shell of transmitter is made of aluminum. In order to shield interference from outside, the shell has been connected with the signal ground in the transmitter. Both the mounting plate and the guide rail cassette are engineering insulation plastics, so it can isolate the transmitter and the earth when install the transmitter.

9. Boundary dimension: 78mm(W)×61mm(L)×65mm(H)(base plate mounted, it is compatible with YD9800 of our company and 3300XL of BN company); 90mm(W)×35mm(L)×70mm(H)(guide rail mounted, it is compatible with 3300XL of BN company). Installation dimension: base plate installation 51mm×51mm, use four M4×12 GB29-76 bolt to install; guide rail installation, can be easily installed on standard 35mm guide rail.

Main Technical Parameters

1. Measurement speed range: 0~65535;

2. Measurement signal frequency range: 0.2~60kHz;

3. Input signal peak-peak value: >2V;

4. Control relay contact capacity: 3A/125VAC,3A/30VDC;

5. Transmission output: 4~20mA (load≤750Ω) Precision is better than ±0.05%F.S;

6. Working temperature: -20~75°C;

7. Working Humidity: 5~90% non condensing

8. Supply voltage: 24Vdc;

9. External power supply for sensors: 24Vdc, short circuit current limitation≤25mA.

OK light bright: Transmitter normal operation
OK light bright, alarm light bright: warn alarm
OK light bright, hazard light bright: dangerous alarm
OK light flickers, alarm light bright: set warn alarm value
OK light flickers, hazard light bright: set dangerous alarm value

Bypass light bright: in a dangerous bypass state

Speed adjustment coefficient
Speed measurement value may have some errors with the actual speed value, by setting speed
adjustment parameter can correct the errors.

Filter coefficient
If there are large fluctuations measured values by various causes in the measurement process, set the filter coefficient appropriately can make it stable.

Threshold voltage
In some applications, the duty cycle of the signal that picked up by speed sensor is very small or very
large, and there is big shaft vibration on the shaft, then adjust the parameter can obtain the best
threshold voltage.

Limiting threshold voltage
Limiting threshold voltage can improve the anti-interference ability of speed measurement. When the
limiting threshold voltage is larger, the anti-interference ability is better. But the limiting threshold voltage
is restricted by speed signal, when the speed signal has a large range, you can set a larger limiting
threshold voltage.

Alarm delay time
Alarm delay in unit of second, in 0 ~ 10 seconds can be set.

Connection instructions

Terminals description

Terminals	Function
24V/I+	Transmitter power positive/ current output positive
I-	Current output negative
GND	Transmitter output negative
UT	15V positive power outer supply for sensor
IN	Sensor signal input
COM	Sensor ground
