Help CenterYD62 Magnetic Speed Sensor
Related Products
-
YD240 Rotation Speed TransmitterNegotiableMOQ: 1 Piece -
Vibration Measuring Instrument Vibration Measurement Tool Accelerometer Monitor YD240 Rotation Speed TransmitterUS$ 99 - 299MOQ: 1 Set
-
YD62 Gear Tooth Speed SensorUS$ 49 - 109MOQ: 1 Piece
-
YD60 Magnetic Rotation Speed Sensor How do You Measure Vibration Vibration Vibration AnalyzersUS$ 45 - 109MOQ: 1 Set
-
YD69 CW/CCW Measurement Dual-Channel Hall Effect Rotation Speed SensorNegotiableMOQ: 1 Set
YD62 Magnetic Speed Sensor uses magnetic resistance as sensing element, it is a new type speed sensor. Core component is magnetic resistance as detection element, and then after a new signal processing the circuit to reduce the noise and make the function better. Compared with the output wave of other types tooth speed sensors, it has many advantages, e.g. the error of measured speed is very small, there is very good consistency of linear characteristic. Its induce objects are magnetic materials or permeability magnetic materials, like magnetic steel, iron and electrical steel. When there are raised magnetic or permeability magnetic materials on the measured body, the sensor output pulse signal that associated with gyro frequency with the measured body moves, so it achieves the purposes of measuring speed and displacement.
The speed sensor has the features as follow:
high sensitivity, high reliability, long life, long trigger distance;
trigger signal is iron (soft) magnetic materials;
long distance transport, strong anti-electromagnetic interference ability;
good impact resistance and vibration resistance.
Technical parameters:
1. Signal frequency: 0~10 kHz
2. Power supply: 12 ~ 25V ( DC )
3. Load resistance≥1.0kΩ
4. Detection distance: 0.5 ~ 2.0mm ( A3 steel, electrical steel )
5. Module of gear: m≥ 1
Gear material: A3 steel, electrical steel 120℃
6. Output signal:
Waveform: a rectangular wave
Amplitude: near the supply voltage
7. Environmental conditions:
Temperature: -40℃~
Relative humidity: ≤85%
8. Mounting screw: M16 x 1 ( or custom it)
Because it is easy to use and install, good generality, so it is widely applied in many fields. Especially in low speed or super-low speed non-contact detection, it has the characteristics that other sensors cannot reach, which fills the gap of magneto-electric sensor with the measurement range 50~5000Hz in domestic (detection distance is only 0.5 mm; proximity switch cannot detect small mould teeth); in middle high speed non-contact detection, it can replace Holl switch directly.
