200A 1325 chinese cnc plasma cutting machine

Specifications

1,Imported Starfire control software
2,Panasonic servo motor
3,Imported Cutmaster welder
4,Arc pressure adjuster
5,CE

           200A 1325 chinese cnc plasma cutting machine





1,Brief introduction:

It is mainly used in steel construction, steel tower, plates, construction machine, boats and ships

manufacturing industry.



2,Picture of chinese cnc plasma cutting machine:



3,Technical parameters:

Model name	chinese cnc plasma cutting machine
Working area	1300x2500mm(1500x3000mm)
Plasma power	60-200A
Cutting thickness	0-30mm(carbon steel)
Cutting speed	0-8000mm/min
Moving speed	0-50000mm/min
Control system	Starfire
Driver	Panasonic servo motor
Welder	Cutmaster(imported from USA)
Arc	Untouched Arc Striking
Files transfer	USB interface
Processing materials	Iron, Carbon steel, Staniless steel, Aluminium sheets, etc
Machine power	8.5kw-10kw





4,Main parts picture of chinese cnc plasma cutting machine:



5,Application fields:

1,This machine is mainly used in the cutting of thick metal plates, such as steel plates, copper plates,

   iron plates, the aluminum plates, galvanized plates, titanium plates and other metal plates.



2, Widely used in Engineering Machinery, Shipbuilding Industry, Mining Machinery, Thick Metal Contour

   Cutting, Rivet Welding Industry.



6,Sample pictures of chinese cnc plasma cutting machine:



7,Features:

1,Panasonic servo motor, Taiwan servo reducer device and high accuracy rack gear transmission.

    Lower noises, stable and accurate coordinate movement.



2,Starfire control system made in Sino-US joint venture and Germany design software FastCAM with

   auto material saving function.



3,American Cut-Master plasma power supply (120A/200A) together with high sensitive arc pressure

   adjuster. Self-adjusting to choose the best distance between plasma gun and working piece

   automatically in order to ensure cutting accuracy.





8,Packing pictures of chinese cnc plasma cutting machine:



9,Exhibition show:







10. Warranty and After Sales Service:

1)One year free warranty, main parts are free of charge when problems happened during the warranty period.

2) Life time free maintenance service.

3)Free training course at our factory with professional engineers.

4)We provide the consumable parts at agent price when you need replacement

5)24 hours online service each day, free technical support with different languages.

6) We provide door to door technical support to agents, if necessary
