Specifications
1. Auto ARC starting2. Taiwan linear square rail
3. Panasonic servo driving
4. Fastcam software
5 CE, FDA
cnc metal cutting machine plasma
1. Plasma Brief Introduction:
Cutting machine plasma is mainly used in steel construction, steel tower, plates, construction machine, boats and ships manufacturing industry.
2. Cutting Machine Plasma Picture:
3. Plasma Features:
1). It can apply to steel plates, copper plates, iron plates, the aluminum plates, galvanized plates, titanium plates and other metal plates.
2). The whole structure is seamless welding steel-structure, not easy to be deformed, simple operation and durability.
3). During the plasma is cutting, if the torch of plasma breaks at any points, take the torch out of the machine, adjust the torch, then the torch will automatically return to break points.
4). Panasonic servo motor, Taiwan servo reducer device and high accuracy rack gear transmission. Lower noises, stable and accurate coordinate movement.
4. Plasma Technical Parameters:
Working Area |
1500*3000mm(59*102 inch) 1300mmx2500mm |
Cutting Thickness |
(120A)3-16mm (200A) 3-30mm ( according to the material) |
Moving Speed |
0-50000mm/min |
Cutting Speed |
0-10000m/min |
Cutting accuracy |
±0.02mm |
Power Supply |
HWAYUAN / American HYPERTHERM (HPR)/ American THERMADYNE |
Input Voltage |
3 Phase 380V |
Power Frequency |
50HZ |
Flies Transfer |
USB Interface |
Arc type |
Untouched type |
Motor |
Panasonic servo motor |
Guide rail |
Taiwan imported linear guide |
Transmit way |
Taiwan imported ball screw |
Operation language |
English or Chinese |
Command |
G code, *uoo, *mmg, *plt |
Optional power source |
American Hypertherm and American Thermadyne |
Spare parts |
Electrode, Electricity nozzle and Water jacket |
|
|
Control system |
DSP or Start control system
|
Applicable material |
Steel, carbon steel, stainless steel, iron plates, aluminum and copper |
5. Plasma Products Warranty and After-Sale Service
1) The machine warranty is 1 year;
2) 24 hours technical support by email or calling;
3) Friendly English version manual and operation video CD disc.
4) Samples for free
5) CE/ISO certificate
6.Advertising Plasma for Cutting Sheet Metal
