Specifications
1.100,000 hours laser lifetime2.Reposition accuracy: 0.05mm/m
3.Free maintenance
4.Special for cutting thin metals
5.CE
Metal Fiber Laser Cutting Machine 200W
1.Brief Introduction:
1).Ideal choice for cutting sheet metal such as Carbon steel, Silicon steel, Stainless steel, and other metal materials .
2).Widely used in sheet metal processing, metal ware, kitchen appliance, household appliance, medical instrument, precision equipment, electric control box, auto parts etc.
2.Picture of Fiber Laser Cutting Machine 200W:
3.Technical Parameters:
Fiber Laser Cutting Machine Main Technical Data: | |||
Laser Type: |
Fiber laser |
||
Laser Power: |
1000W / 500W / 400W /300W/200W |
||
Working area: |
1300 x 2500mm |
1500 x 3000mm |
2000 x 4000mm |
Working Table Structure: |
Fixed / Pallet Working Table |
||
Control System: |
PMAC full-closed loop servo control |
||
Driving Mode: |
Double ball screw driving / Double gear rack driving |
||
Idle/Processing Speed: |
60m/min/24m/min |
||
Positioning Accuracy: |
0.05mm |
||
Cooling System: |
High precision constant temperature water chiller |
||
Protection System: |
Enclosure protection |
||
Power Supply: |
AC220V ± 5% 50/60Hz/AC380V ± 5% 50/60Hz |
||
Total Power: |
7.5KW/6KW~20KW |
||
Support Format: |
PLT, DXF, BMP, AI, DST, DWG, etc. |
||
Floor Space: |
5.4m x 4.6m (shuttle working table) |
||
Other Standard Collocation: |
Metal nesting software, dual-pressure gas route of 3 kinds of gas sources, dynamic focus, remote controller, etc. |
||
4.Features:
1).Fiber Laser Metal Cutting Machine has faster cutting speed and higher quality cutting result compared to other cutting solutions.
2).The efficiency of a fiber laser far exceeds traditional YAG or CO2 laser equipment. The fiber laser beam is capable of cutting reflective metals.
5.Main Parts Picture:
6.Advantages:
1).Compact structure, small floor area.
2).Stability and reliability of light path system and control system.
3).High performance and low operating cost, famous fiber laser with up to more than 100 thousand hours life-cycle.
7.Packing Details:
8.Exhibition Show:
9.Factory Show:
10.Warranty and After Sales Service:
1).One year warranty, the machine with main parts(excluding the consumables) shall be changed free of charge if there is any problem during the warranty period.
2).Maintenance free of charge during lifespan.
3).Free training course at our plant.
4).24 hours on line service each day, free technical support.
5).Machine has been adjusted before delivery, operation disk is included.
6).We will provide the consumable parts at an agency price when you need replacement.
