Specifications
HF-6A small piling rig1.multifunctional type
2.electric for power,easy operate
3.max depth300m,dia300~1800mm
multifuctional drillig rig, HF-6A small piling rig,can drill depth upto 300m, drilling diameter 300~1800mm
1. Application of HF series water well drilling rig for sale
Since our establishment in 2004, we have been devoting ourselves to researching and developing easy-operation, highly-efficient and large-capacity drilling rigs.
Designed for multiple functions,our HF series water well/core drilling rigs are designed for geological exploration, water well drilling, soil sampling, core sampling(normal coring and wireline coring), pile drilling, etc.
2. technical parameters about water well drilling rig for sale
Main features
1. HF-6A is multifunctional type, mainly used for water well drilling, borehole drilling and piling foundation,etc.
2. it can adapt various stratum: soil, sand, clay, gravel, rock, etc
3. stable performance, with high pore forming efficiency and good pile formation quality.
4. max drilling diameter is 300m, drilling diameter is 300~1800mm;
Technical paraments
Mechanical features |
Specifications |
|
Dimensions(M) |
9.30*2.50*3.10 |
|
Transport dimensions(M) |
9.30*2.28*2.80 |
|
Weight(kg) |
9500 |
|
Drilling diameter(mm) |
300-1800 |
|
Drilling depth(M) |
300(when dia. Is 600mm) |
|
Max.Weight of drill bit(kg) |
5000 |
|
Impact stroke(mm) |
Max.850,Min.700 |
|
Rate of impact(time/min) |
38-42 |
|
Electric motor |
Model YL280M2-6,55KW 980R/Min |
|
Height of mast (M) |
Single bar8.5-9.5m; Double bar12.5m |
|
Load capacity of mast(kg) |
50000 |
|
Hauling speed(km/h) |
30 |
|
Lifting capacity of Hoist(N) |
Front hoist |
20096 |
Back hoist |
68357 |
|
Steel wire rope of coiling block(M) |
Front coiling block |
6×37-φ18 200-250(Left turning) |
Back coiling block |
6×19s+IWRC 200-300(Left turning) |
|
Wheel |
Tire size |
7.50-20 |
Steel ring size |
20×7 |
|
3,Designs of HF series small piling rig
Innovation is the key to our success: During these years, we continually make new designs on our products to
make them easier for clients to use.
Hydraulic chuck: It is designed to save the trouble from ball chuck.
Slide: It is designed to move the machine backward or forward when you need to lift/change the drill rod or adjust
the drilling position.
Trailer: 2-wheel, 4-wheel, 6-wheel. It is designed to move the drilling rig with tractors or such pulling devices.
Truck mounted: Easy to move and operate, they are also with hydraulic systems.
Crawler: Self-propelled, able to clime, suitable for complex terrains.
Hydraulic system: Tower and support. It is designed to decrease labor cost; two men are more than enough
to operate the drilling rig with hydraulic system.
Digital control: Multiple data display, easy controlling and monitoring, very convenient and efficient for
geological study.
4. Production ability(small piling rig)
We have more than 50 sets of processing equipment to ensure the quality of our product, which has proved worthy by our client’s recognition. And these equipments ensure large production capacity and adequate stock.
We have all the small models in stock all year long and the bigger ones ready within 15-30 days.
5. Customers(small piling rig)
With all the effort put in, we have successfully marketed our products to almost every corner of the world. Here are the pictures of our clients’ visits and our clients’ on-the-site operation.
6. Packing(small piling rig)
To protect drilling rigs during sea transportation, we give them proper packing.
HF130, HF80,HF150E,HF150,HF200,HF30: Wooden case
HF-3,HF-4,HFDX-6.HF-8,HFT200,HFT350B: Plastic woven bag
Spare parts: Wooden case or plastic woven bag
HFT-200, HFT-3: Nude, main machine in plastic woven bag.
8. Quality guarantee(small piling rig )
Our products has been authorized and certified by TUV and ISO9001:2008. We guarantee the quality of the machines for one year after the trial run (excluding the wearing parts), but not exceeding 15 months from the date on which machines leave the factory.
