Strong ability! duplex mud pump BW850-5 for drilling rig
Specifications
BW850-5 mud pump for drilling rig
1,Strong ability
2,Displacement: 850l/min
3,horizontal type
4,for water well drilling
BW-850/5 Mud Pump Specifications | |
Type |
Horizontal single urn twin-action |
Cylinder inner diameter(mm) |
140 |
Stroke(mm) |
260 |
Rated flow(L/min) |
850 |
Rated pump speed(min-1) |
66 |
Rated discharge Pressure(Mpa) |
5 |
Inlet tube diameter(mm) |
152 |
Output tube diameter(mm) |
64 |
Triangle belt standard |
C 6300 |
Triangle belt root |
7 |
Rotate speed(r/min) |
918 |
Weight(Kg) |
3100 |
Power |
Electromotor 90Kw |
Hanfa Group established in 1998 is a key enterprise in the industry of geological exploration and water well field, with the ability to research, manufacture and market.
Presently,it has three subsidiaries which are Zhengzhou Hanfa Prospecting Mchinery Co.,Ltd ,Zhengzhou Hanfa Imp & Exp Trading Co.,Ltd and HK Hanfa Imp Trading Co.,Ltd.It has experienced engineers , professional R&D team , special after service team ,world class sophisticated equipment and advanced technology guarantee the best quality drilling equipments and best service to its customers.
Now, the Group pursues high standard manufacturing and qualified products. It has more than 20 species such as water well drilling rig, core drilling rig, engineering drilling rig, DTH drilling rig, horizontal directional drilling rig, etc. These machines are mainly used in geological prospecting, exploration of railway and highway engineering, mining, SPT, water well, geothermal well etc. Some of them won the Scientific and Technical Advance Prize or the National Scientific Research Achievement Prize. All the products have passed the quality system certification of ISO9001:2000 and are national inspection-free products.
At Present, Hanfa Group is the biggest exporter of drilling rigs in China. It has exported to more than Sixty countries and different regions, such as Southeast Asia, South America, Africa, Eastern Europe, Russia etc. Excellent quality and perfect service gain the consistent praise from customers. Depending on the stable and lasting capabilities, the brand of “HF” is also well-known and influential in the international market.
All the time, "Client first, Service best" is our principle. Customers are our pilot, service is our heart. Your satisfaction is our eternal pursuit. Let’s hand in hand and create a better tomorrow!
