Specifications
1. Engineering Rig2.Improves the efficiency by 3-5 times
3.good quality
4.Drilling diameter 2m
1.KP2000A Type drilling equipment uses rotary to drive bar for driling, with the electric machine for power, in the mode of mechanical drive.
2. Partial action appiles hydraulic drive, with large torque, high efficiency and convenience for use.
3. This drilling machine is applicable to pore forming construction of various foundations, drilling projects such as heavy caliber shallow water well, small coal mine silo and national defense project.
4.This drilling machine is driven by hydraulic pressure, being double layer chassis type. The upper chassis can move back and forth on the lower one. The displacement of lower chassis can be selected among the three forms (i.e. prise, steel, wheel and rolling bar) at will according to the need of construction.
5. The major Diameter Engineering Drilling Rigis equipped with patent product ZF150 type circulation system for both positive sha negative use, which can improve the drilling rig work efficiency by 3~5 times.
Main Technical Parameter
KP2000A Type engineering drilling rig |
ZF150 type circulating system for both positive and negative use |
||||
Dynamic power(kW) |
45 |
|
3PNL |
6PS |
|
Drilling depth(m) |
80 |
||||
Power(kw) |
22 |
30 |
|||
Hole Diameter rock formation(m) |
2 |
||||
Delivery lift(m) |
22 |
12 |
|||
Rotary speed(r/m) |
10 30 43 63 |
||||
Suction lift(m) |
|
7.5 |
|||
Rotary torque(kN.m) |
43.8 14.6 10.2 7.0 |
||||
Flow capacity(m3/h) |
108 |
180 |
|||
Mass(t) |
11 |
||||
Our products has been authorized and certified by TUV and ISO9001:2008. We guarantee the quality of the machines for one year after the trial run (excluding the wearing parts), but not exceeding 15 months from the date on which machines leave the factory.
