HF830 Hydraulic Rotary Pile Drilling Rig for Sales
• It adopts telescopic mast which has simple structure, high durability, low cost and makes the repair more convenient.
• The power head adopts high position-oriented frame structure guarantees the verticality of kelly bar, which makes construction more convenient, and improves the working efficiency and safety.
• The power head adopts unique patented structure, which features low cost, not easily damaged and convenient for repair.
• Main winch: it adopts originally imported Italy hydraulic motor. It is more flexible and can be lowered freely, and the lifting speed is up to 80m/min, which greatly improves the work efficiency. The main winch is allocated at the front right of the operator, so the operator can observe its work condition and avoid twisted ropes.
| HF830 Drilling Rig Data | |||
|
Max drilling depth
Drilling Diameter |
m
mm |
30
600-1600mm |
|
| Overall measurement | Working dimensions | mm | 13200*3200*7456 |
| Transport dimensions | mm | 8200*3200*3325 | |
| Machine weight | kg | 36000 | |
| Engine | Type | 6BTA5.9-C (Cummins) | |
| Reted power | KW/rpm | 108/2100 | |
| Form | Pressurize/ direct-injection | ||
| Rotary drive | Max torque | KN.m | 80 |
| Rotation speed | r/min | 1--22 | |
| Crowd cylinder | Max push | KN | 150 |
| Max pull | KN | 100 | |
| Max stroke | m | 3 | |
| Main winch | Max line pull | KN | 120 |
| Max line speed | m/min | 70 | |
| Line diameter | mm | 24 | |
| Auxiliary winch | Max line pull | KN | 60 |
| Max line speed | m/min | 50 | |
| Line diameter | mm | 18 | |
| Adjustment | Crutch angle | ° | ±3(horizontal) |
| 0-100(forward/backward) | |||
| Chass | Max travel speed | km/h | 3 |
| Max climing speed | 40% | ||
| Min ground clearance | mm | 460 | |
| Track width | mm | 800 | |
