Specifications
HF200 wheeled drilling machine for water1.200m Depth
2.easy to operate
3.hydraulic&trailer mounted
4.can drill rock
HF200 wheeled drilling machine for water ! Easy to operate&transport
1,Drilling depth can reach 30-200m
2,Steels quality is good, torque is large
3,Easy operation
4,For various complex strutam, such as pebble bed, aggregate bed.
5, Saving money, compact construction, easy moving
6, For water well, bore holes, coring, taking samples, geological exploration, exploration of high building construction, rivers construction, civil water well
HF200 water drilling equipment
Specifications | ||
Unity machine parameter | ||
Drilling depth |
30--200m |
|
End hole caliber |
300-75mm |
|
Drill rod caliber |
50mm |
|
Drilling angle |
90°~75° |
|
Drill weight (No include power) |
910kg |
|
Unity machine dimensions |
2.5×1×1.3 2.5×0.9×1.3m |
|
Spindle | ||
pindle speed |
64,128,287,557r/min |
|
Spindle stroke |
450mm |
|
Hoist | ||
Max.single line hoisting capacity |
2000kg |
|
Single line lifting speed |
17,35,75,151r/min |
|
Tightrope caliber |
12.5mm |
|
Tightrope cubic measure |
35m |
|
Hug floodgate caliber |
254mm |
|
Hug folldgate belt width |
70mm |
|
Distance between drill and hole |
400mm |
|
Mud pump | ||
Type |
Horizontal single urn twin-action |
|
Displacement |
170L/min |
|
Diesle engine |
S1110 22HP |
|
Electric motor |
Y160M—4 15kw 1440r/min |
|
Maximum pressure |
1.5Mpa |
|
Work pressure |
0.7Mpa |
|
Water inlet caliber |
40mm |
|
Water to exit caliber |
30mm |
|
Triangle conveyer belt |
B1728mm |
|
