Specifications
water well drilling machine1.high efficiency, large torque
2.strong drilling capacity
3.can drill 600m depth
4.trailer type
strongest drilling capacity,water well drilling machine S600
I. Applications and Features of water well drilling machine
1.Professional for water well drilling.It was awarded the National Scientific Research Achievement Prize by Chinese government and highly recommoned by its users for good quality and operation.
2.It’s well suited for exploring water sources,drilling industrial,agricultural,civil wells,and constructing piles and
ventilation holes for underground cannels.The drill can work in various geological conditions,can wok in
various geological conditons,applying the rotary drill and direct/reverse circultaion.
3..Convenient to use.Possesses an integral drill tower and a partly hydraulic operated.
4.It is characterized by trailer moving ,mechanical transmission,partially hydraulic lift/lowering,easy delivery and high degree of mechanization.It opetates very efficiently drilling deep,large liameter holes with high torque.
II. Main Technical Parameter of water well drilling machine
Max.diameter of turntable |
650 |
Drilling Depth(mm) |
600 |
Turntable Speed(r/min) |
22,59,86,126 |
Torque(KN.m) |
13.7,5.1,3.5,2.3 |
Effective Heigh of Rig(m) |
14 |
Load of Rig(kN) |
294 |
|
Averall dimensions (m)
(L×W×H) |
Railing State 10×2.8×4.1 |
|
Working State 5.65×4.15×16.7 | |
Weight (t) |
10.5 |
