Specifications
2012 hot sales drilling rig machine, drilling rig equipment1.water well
2.civil well
il&clay sample drilling rig
4.rock
1. Hydraulic trailer type water well drill rigs application
Geological general investigation and exploration, road and tall building basic exploration, kinds of hole in concrete structure, river levees,roadbed grouting hole drilling and direct grouting, civil wells and earth central air conditioner, etc
2. Hydraulic trailer type water well drill rigs feature
A.Hydraulic trailer type water well drill rigs can drill up to 600 m depth(end diameter is 75mm),Max.drilling diameter comes to 300mm.
B.Hydraulic trailer type water well drill rigs is hydraulic driven,hydraulic mast and foot clamps,high working efficiency and good performance.
C.Hydraulic trailer type water well drill rigs mounted on trailer chassis,integrated diesel engine,double bases,all greatly improve the practice of our HF-3.
D.Hydraulic trailer type water well drill rigs is rock expert high efficiency drilling rig.
Drilling depth |
m |
600 |
Open hole caliber |
mm |
300 |
End hole caliber |
mm |
75 |
Drilling rod |
mm |
Φ60 |
Drilling angle |
90°-65° |
|
Spindle | ||
Spindle forward speed |
r/min |
57-1024 |
Spindle reverse speed |
r/min |
45-212 |
Spindle stroke |
mm |
560 |
Spindle inner diameter |
mm |
96 |
Spindle lifting capacity |
KG |
6000 |
Hoist | ||
Single line lifting speed |
m/s |
0.515 0.894 1.421 1.948 |
Hug floodgate belt width |
mm |
90 |
Tightrope caliber |
mm |
12.5 or 14 |
Hoist single line lifting capacity |
KG |
3000 |
Reel caliber |
mm |
200 |
Reel cubic measure |
m |
30 |
Mud pump | ||
Horizontal double actuator | ||
Displacement |
L/min |
200,125 |
Triangle conveyer belt type |
B×5 |
|
Work pressure |
Mpa |
4.6 |
Water inlet caliber |
mm |
65 |
Water to exit caliber |
mm |
37 |
Oil pump | ||
Duplex gear oil pump F532/F314 | ||
Front displacement,pressure |
32L/min 20Mpa |
|
Behind displacement,pressure |
14L/min 20Mpa |
|
Drilling rig Power | ||
Diesel engine |
Hp |
76HP |
Electric motor |
KW |
41KW |
