HFDX-2 full hydraulic core sample drilling rig for mining
- 100 Set / Sets per Month
- Shanghai Tianjin Qingdao
- T/T L/C D/P D/A Credit Card PayPal
- 3NB9/1.8-7.5 mining mud pump is used for providing cooling and flushing fluid during rock core or coal seam drilling
- 2NB3/1.5-2.2 mining mud pump is a vertical, double cylinder, single acting plunger pump
- The 3NB-250/6-15 reciprocating mud pump provides washout fluid to the borehole during core drilling with the three-cylinder plunger
- Coal mine tunnel drilling rig ZLJ350 head can be turned
- China Xy-200 Water Well Drill Rig Machine for Soil and Rock Drilling
- 100 Meters Xy-1A Water Well Drilling Rig Machine Equipment
Product Details
Condition: | New | Type: | Core Drilling Rig | Power Type: | Diesel |
Place of Origin: | Henan, China | Brand Name: | HF full hydraulic diamond core drilling rig | Model Number: | HFDX-2 full hydraulic diamond core drilling rig |
Usage: | Other, core | Voltage: | 220v/380v | Power(W): | 33KW |
Dimension(L*W*H): | 3500*1500*1300mm | Weight: | the largest part not more than 100kg | Certification: | ISO, CE |
Warranty: | one year for the main machine | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
HFDX-2 full hydraulic core sample drilling rig for mining
1. it can drill 300m with Φ55mm drill rod, 200m depth with Φ71mm drill rod.
2. it is full hydraulic control, very strong and high drilling efficiency.
3. it is separate in structure, small in size, light in weight, flexible in movement and convenient in operation.
4. the mast have sliding, extending and retracting function, convenient and stable for drilling.
5. the hydraulic pump is driven by explosion-proof electric motor.
6. it is a professional machine for underground drilling, diamond coring for mining exploration, suitable for diamond drilling with wireline coring technique;
HFDX-2 portable full hydraulic core borehole drilling machine main features:
1. Full Hydraulic and Drill Head model.
The drill head rotation is realized with four hydraulic pumps driven by five diesel engines; this also makes the feeding hydraulic cylinder system realize its full stroke feeding in both higher and lower speed.
2. In good disassemblability.
The rig is adopted fission style in design, including power unit, hydraulic oil tank, manipulation platform and operation mechanism, i.e. the drilling section. So they are in light weight and can be carried by man power or animal power. The rig can be applied and performed in narrow space for drilling of hole at 45°~90° with stronger adaptability.
3. Strong techniques adaptability.
Besides diamond drilling with wire line coring technique, it is in strong techniques adaptability. It is applicable for the drilling and feeding requirement of any other stratum.
HFDX-2 portable full hydraulic core borehole drilling machine technical data:
Item | Model | HFDX-2 drilling rig |
Basic parameter of drilling capacity | BQ | 350m |
NQ | 230m | |
HQ | 120m | |
Power unit | Model | 2 sets double cylinder diesel engine |
Rated power of single engine | 33KW | |
Rated speed | 2500rpm | |
Drill head | Max. Spindle torque | 334~930N·m |
Max. Spindle speed | 0~900rpm | |
Feeding system (feed with hydraulic cylinder) | Feeding stroke | 1700mm |
Lifting capacity | 50kN | |
Feeding capacity | 25kN | |
Main hoist | Lifting capacity | 18kN (single-wire) |
Lifting speed | 84m/min | |
Rope capacity | 30m | |
Steel wire diameter | 12mm | |
Wire line winch | Lifting capacity | 8.4kN (bare drum) |
Lifting speed | 90~240m/min | |
Rope capacity | 500m | |
Steel wire diameter | 6mm | |
Mud pump | model | BW-100A |
Overall dimensions (L*W*H) Main machine (in transport position) | 3500*1500*1300mm | |
Dimensions of the disassembled parts (without mud pump) | The largest part not more than 100kg |
our engineer will offer after-sales service 24 hours, you can call us on:0086-371-55019555 or send email to us at: admin(at)hanfaa(dot)com;
HANFA have participated in China, kazakhstan, Chile, Africa, Canada and other countries large-scale exhibitions, the products were praised by local people.HANFA was interviewed by local TV many times.On the day of the exhibition,countless order has been signed successly.
