Mining Drilling Machine, Popular HF180Y Crawler Down-the-hole Drill

Mining Drilling Machine, Popular HF180Y Crawler Down-the-hole Drill photo-1
US$ 40,000 - 50,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Other, DTH type
Power Type:
Diesel
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai Tianjin Qingdao port
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Type Other, DTH type
Power Type Diesel
Place of Origin Henan, China
Brand Name HF
Model Number HF180Y
Usage Coal
Voltage 220V/380V
Dimension(L*W*H) 5020*2040*3200
Weight 6.8T
Warranty 1 year
After-sales Service Provided Engineers available to service machinery overseas

Specifications

Down-the-hole Drill
1.crawler type, easy to tranpsort
ing with mud pump or air compressor
3.high efficiency

 Down-the-hole Drill



Mining drilling rig, popular HF180Y Crawler DTH Drilling Rig





Technical Parameter



Product Description



HF180Y track-type water well drilling rig is lightweight, efficient, multi-purpose drilling equipment, which can adopt to air, foam or mud for rotary or percussive drilling according to different geological conditions.
It is widely used in industrial and agricultural water conservancy projects, such as water wells, testing wells or other exploration boreholes, particularly in drilling holes for geothermal heating. It can be used for the reinforcement of basis foundation, loose gravel drilling with casing, rock drilling work and other various engineering requirements.



Drilling diameter (mm)

90~215

Drilling depth(m)

180

Work Pressure(Mpa)

1.05~2.46

Consumption (m³ /min)

16~30

Drill pipe length (m)

3

Drill pipe diameter (mm)

76

Dimensions (L*H*W) (mm)

5020*2040*3200

Grade ability

25 degrees

Footage efficiency(m/h)

5~20

Travelling speed(Km/h)

0~2.5

Total weight(t)

6.8

Feed systems



Axle pressure (N)

40820

Lifting power (N)

62000

Rotary torque (Nm)

3200

Rotary speed

0~130

Host Power (Kw)

55



 Mining Drilling Machine, Popular HF180Y Crawler Down-the-hole DrillMining Drilling Machine, Popular HF180Y Crawler Down-the-hole DrillMining Drilling Machine, Popular HF180Y Crawler Down-the-hole Drill
