Home > Manufacturing & Processing Machinery > Drilling Rig > Mine Drilling Rig > HF130 Solar Photovoltaic Pile Drilling Machine
HF130 Solar Photovoltaic Pile Drilling Machine
US$ 20,000 - 30,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Rotary Drilling Rig
Power Type:
Diesel
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao other ports also available
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
For Farm Irrigation Use, Small Volume, Light Weight,easy Operate HF150E Electric Power Saving EquipmentUS$ 1 - 2,350MOQ: 1 Set -
HF856A Hydraulic Rotary Piling Driver 38 Tons Large Torque 80 KN.m Engineer Oversea Service okNegotiableMOQ: 1 Set
-
HF856A Hydraulic Rotary Piling Driver Engineer Oversea Service ok for Bridge Rode Foundation BuildingNegotiableMOQ: 1 Set
-
HF856A Hydraulic Rotary Piling Driver 38tons Large Torque 80 KN.m Engineer Oversea Service ok Foundation Construction UsingNegotiableMOQ: 1 Set
-
Powerful HF856A Hydraulic Rotary Piling Driver Engineer Oversea Service ok for Bridge Rode Foundation BuildingNegotiableMOQ: 1 Set
Condition
New
Type
Rotary Drilling Rig
Power Type
Diesel
Place of Origin
China
Brand Name
HF
Model Number
HF130
Usage
Other, small piles
Voltage
Diesel Engine Driven
Power(W)
56kw
Dimension(L*W*H)
4460mmx1950mmx2460mm
Weight
4.36ton
Certification
CE, SGS, BV
Warranty
1year for machine machine
After-sales Service Provided
Engineers available to service machinery overseas
HF130 Solar Photovoltaic Pile Drilling Machine
Bore diameter(hammer) |
90-300mm |
Bore depth |
20-100m |
Air consumption |
10-26m³/min |
Air pressure |
0.7-1.6Mpa(medium) 1.6-2.46Mpa(high) |
Pipe diameter |
76mm/89mm |
For rock |
F=6-20 |
Bore diameter(screw) |
Max 400mm |
Bore depth |
0-30m |
Screw pipe diameter |
130-400mm |
Once promotion |
2000mm |
Skid pitch |
100° |
Swinging angle of skid |
Left and right total 40° |
Rotation speed |
0-70r/min |
Host power |
56Kw |
Climb ability |
35° |
Dimension(L*W*H) |
4460*1950*2460(mm) |
weight |
4360Kg |
Walk speed |
0-2.5km/h |
