Specifications
HF200L crawler multi-function rotary drilling rig1.easy to move
2.diesel engine/electric motor
3.multi-functional
4.hydrau
Crawler rotary drilling rig for selling!HF200L crawler multi-function rotary drilling rig
I.Introduction of Geological exploration drilling rig
>it can drill Max200m depth,Max 500mm drill diameter
II. Technical parameter of Geological exploration drilling rig
Main machine technical parameter | |||
Drilling depth | 200m | ||
Drlling diameter | 300mm | ||
End diameter | 75mm | ||
Drilling pipe diameter | 50mm | ||
Drilling angle | 90°~75° | ||
Spindle | |||
Spindle speed | 64,128,287,557r/min | ||
Spindle stroke | 450mm | ||
Hoist | |||
Max.single line hoisting capacity | 2400kg | ||
Reel lifting speed | 17,35,75,151r/min | ||
Reel diameter | 140mm | ||
Wirerope diameter | 13mm | ||
Wirerop cubic measure | 35m | ||
Hug floodgate diameter | 260mm | ||
Hug floodgate belt width | 70mm | ||
Distance between drill and hole | 400mm | ||
Power | |||
Diesel engine | s1105 Model, 22HP | ||
Electric Motor | Y160M—4 ,15kw 1440r/min | ||
Mud pump | |||
Type | Horizontal single urn twin-action | ||
Displacement | 170L/min | ||
Maximum pressure | 3.0Mpa | ||
Work pressure | 1.5Mpa | ||
Water inlet caliber | 40mm | ||
Water to exit caliber | 30mm | ||
Triangle conveyer belt | B1728mm | ||
Hydraulic pump | |||
specification | CBT—F—314 | ||
Triangle conveyer belt | B1100×1 | ||
Useful | |||
Geology general check exploration,Earth physics exploration,Road and high layer building ground survey,water Well,Blast opening etc drilling engineering | |||
