HF-7 Wire-line Coring Drilling Rig,which Can Drill 2200m

HF-7 Wire-line Coring Drilling Rig,which Can Drill 2200m thumbnail-1
HF-7 Wire-line Coring Drilling Rig,which Can Drill 2200m photo-1
US$ 32,099 - 45,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Core Drilling Rig
Power Type:
Diesel
Contact Supplier Request Quote Chat Now
Zhengzhou Hanfa Prospecting Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Tianjin Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Core Drilling Rig
Power Type Diesel
Place of Origin Henan, China
Brand Name Hanfa
Model Number HF-7
Usage Other, minera deposite, core drilling
Power(W) 177
Dimension(L*W*H) 3260 x 1280 x 2290mm
Certification CE, ISO
Warranty one year
After-sales Service Provided Engineers available to service machinery overseas

Specifications

wire-line coring drilling rig
1.large range, reasonable speed
2.Large capacity of power unit
3.Large output torque
4.ISO9001

  HF-7 wire-line coring drilling rig,which can drill 2200m



I.Advantages of wire-line coring drilling rig HF-7:



1.large range and reasonable drilling speeds

2.Large capacity of power unit

3.Large output torque

4.Hoister in horizontal arrangement

5.equip with hydraulic brake, braking easily and quickly

HF-7 wire-line coring drilling rig,which can drill 2200m



II. Application of wire-line coring drilling rig HF-7:



Metallic and nonmetallic solid mineral deposits prospecting; shallow oil and natural gas exploration and exploitation; geothermal well exploitation, mine ventilation and drainage ; also for large hole diameter basic pile construction. The drilling rigs can be widely used in geology, metallurgy. Coal, hydrogeology well and engineering and other industries fields



HF-7 wire-line coring drilling rig,which can drill 2200m

III. Technical parameter of wire-line coring drilling rig HF-7:



Unity machine parameter
Drilling depth600-2200m
Drill Rod made in ChinaΦ50 x 4.752200m
Φ50 x 52000m
Φ60 x 61450m
Φ71 x 51659m
Φ73 x 71000m
Φ89 x 51300m
Φ89 x 10600m
Internally Thickeded Drill RodBW2200m
NW1700m
HW1150m
Wireline Coring Drill RodBQ2200m
NQ1700m
HQ1150m
PQ800m
BCQ2500m
NCQ2000m
HCQ1550m
PowerElectric motorY250M-4   56KW   1500r/min
Diesel Engine6BT5.9-85 85KW   2000r/min
Drilling angle90° ~75°
Drill machine moving stroke500mm
Dimension3260 x 1280 x 2290mm
Weight ( power not included )3350kg
Spindle
Spindle Bore Diameter118mm
Spindle stroke800mm
Spindle max. torque7500N.m
Spindle max. lifting capacity180kn
Spindle max. pressure force120kn
Spindle Speed           Electric motor 1500r/minForward Rotation41; 70; 122; 155; 178; 265; 268; 469; 681; 1016r/min
Backward Rotation41; 156r/min
Spindle Speed           Diesel Engine 200r/minForward Rotation54; 94; 163; 207; 237; 353; 358; 625; 908; 1355r/min
Backward Rotation54; 207r/min
Hoist
Max.single line hoisting capacity60KN
Wirerope caliber20mm
Roller capacity of wireline length102m
Single line lifting speedPower rotation Speed 1500r/min0.438; 0.758; 1.322; 1.921; 2.865m/s
Power rotation Speed 2000r/min0.584; 1.011; 1.762; 2.560; 3.820m/s
Transssion gearbox
Auto gearbox
Hydraulic oil box
Duplex gear oil pumpCBY2032/K1020
Displacement32/16 ml/r
Work pressure20 Mpa
Max. pressure25 Mpa
Water brake
Work rotation speed700-1800r/min
Single line balance speed3-8m/s
Single line balance load45KN







HF-7 wire-line coring drilling rig,which can drill 2200m



Project case of wire-line coring drilling rig

HF-7 wire-line coring drilling rig,which can drill 2200m



About us
