Specifications
S2600 Type Hydrongrapic Water Well Drilling Machine1. Drill depth: 2200-2600m
2. Diameter: 450mm
S2600 Type Hydrongrapic Water Well Drilling Machine
The drilling Rig is applicable to the exploitation of deep underground water and the development of superficial terrestrial heat,petroleum and natural gas.It is a rotary disk drilling machine of mechanical driving.
It can be used for rhe drilling of positive and negative circulation and the drilling with multiple process air. It possesses the advantages of safe,reliable and labor-saving operation,high automaticity,and low cost of operation.
With a quick drilling speed,S2600Type well drill has a tension of the single rope for single winch of 105KN.With rhe drilling rod of dia 89,it can drill up to the depth of 2600m;and weth the drilling rod of dia 127,it can drill up to the depth of 2200m,which is widely used.
The drill has a big diameterof through hole of 445mm,and it can satisfy the requirements for the drilling of water well.With strong lifting capacity,it can be used for the construction of other resource holes including terrestrial heat.
The drill can meet the process requirements of various constrctions.The output rotating speed of the rotary disk ranges from 43r/m(Min.speed)to 156r/min(Max.speed).Mechanical catheads can be selected to dismantle the drilling tool together with tongs or to remove the drilling tool together with the rotary disk.
With flexible power matching,two Y280M-4×(2×90KW)motors or two 6135AN-2(2×150HP)diesel engines can be selected.
Main Technical Parameter
Drilling capacity |
Drilling rod specifications(mm) |
89 127 |
Corollary active drilling rod |
108×108×12000 |
||||
Drilling depth(m) |
2200-2600
|
Cathead |
Catheads and tongs can be useed to remove thedrilling tool when forks arenot used to remove the drilling tool
|
|||||
|
Rotary disk
|
Diameter(mm) |
dia450 |
Power enginemotor |
Type |
2×Y280M-4 |
|||
Rotation speed(r/min)(positive,reverse) |
43 63 93 156 |
(r/min)Rotation |
1500 |
|||||
Output Torque |
30 22 16 9 |
(HP)Power |
244.8 |
|||||
Hoist |
Rate lifeing capacity of single rope(layer 2) |
105 |
Power enginediesel engine |
Type |
2×6135AN-2 |
|||
Lifting speed(layer2) |
1.1 2.4 4.1 |
(r/min)Rotation |
1500 |
|||||
Diameter of wire rope 6x(19)(mm) |
dia 24.5 |
(HP) Power |
408 |
|||||
Watet brake |
Mode |
Duplex water brake |
Weighr of overall unit(t) |
9.96 |
||||
Impeller diameter(mm) |
dia 580 |
Overall dimensions of the main engine(L×W×H)(mm) |
7575×2948×1760(motor)
|
|||||
Corollary hook |
Pulley block |
5×6
|
Overall dimensions of the main engine(L×W×H)(mm) |
7575×5370×1760(diesel)
|
||||
Max.load of hook (kN) |
800 |
|||||||
Lifting speed of hook (m/s) |
0.11,0.24 ,0.41 |
|||||||
