Rock exporter ,HF150Y air compressor DTH drilling rig

Specifications

HF150Y air compressor DTH drilling rig
1)hydraulic&crawler type
2)rock expert,high efficiency

  Rock exporter ,HF150Y air compressor DTH drilling rig



HF150Y High Air Pressure DTH Drill Crawler open with a low energy consumption, high efficiency, easy to transport and field construction superior technical performance, vehicle movement organizations from the hydraulic system to achieve, and only washed the source of the wind machine consumption, resulting in Air Machine Matching saves in a complete set of equipment procurement costs.



Rotary organizations to adopt a new dual-motor turret to make it to the open-air blast drilling operations when drilling large holes to maintain a strong rotary torque output, dragging air compressor, it has the mobile and flexible and climbing ability, suitable for rugged venue operations, perforation shift convenience features.



Whole diameter 105-165mm, with a piercing, high efficiency, Maintenance is simple, high reliability, is a mining, highway, water conservancy, power station construction and other construction ideal for drilling rig operations.





 Technical data





(Mpa) Wind pressure	1.2—2.46
(m³/min) Air consumption	11--25
(mm) Drilling diamete	105---165 (max:203)
(m) Drilling depth	level 50m,down 80m
(mm) Once promotion distance	3000
(mm) Drill diameter	76
(mm) Skid compensation	1200
(N) Maximum lift force	26000
(°) Guide shell lutting	up and down total 100
(°) Guide shell swing angle	Left and right total 100
(°) Boom lift angle	up and down total 70
(°) Boom swing angle	Left 45, right 45
(°) Grade ability	30
(mm) Chassis ground clearance	300
(Km/h) Travelling speed	0-2.5
(r/min) Back to the transit speed	0--90
(N.m) Rotary torque	3000
(Km) Host Power	56
(f) For rock	6---20
(kg) Total Weight	6300
(mm)Dimension (L * W * H)	5800*2070*2400
Note: The Company’s products continued to improve; various design and technical specifications may change at any time, without any additional notice or obligation.
