130m Capable Drilling Rig! HF130 Water Well Drilling Machine

Name: 130m Capable Drilling Rig! HF130 Water Well Drilling Machine
Brand: Hanfa
SKU: 101793075
Availability: InStock

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Type:

Rotary Drilling Rig

Place of Origin:

Henan, China

Zhengzhou Hanfa Prospecting Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao Shanghai etc

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Rotary Drilling Rig

Place of Origin Henan, China

Brand Name Hanfa

Model Number HF130

Usage Other, core sampling

Specifications

HF130 core drilling rigs,water well drilling machine
1 Durable quality
2 Easy to use
3 Popular model in Africa&South Americ

130m Capable drilling rig! HF130 water well drilling rig

Specially recommended

This machine gained 3 national practical new-type patents invention.

To be equipped with hexagonal vertical shaft and hexagonal drive drilling rod, with strong rigidity and big transfer torque.

To be provided with cone plate friction clutch, being facile to operate, with big transfer torque.

To adopt rolling bearing type hoist, with wide brake band and big lifting capacity.

To be equipped with speed reducer and sludge pump, being integrated structure.

The entire machine is featured by strong adaptability, high motive power, low cost and broad compatibility.

To be provided with hydraulic control pressure feed mechanism for the purpose of improvement of construction efficiency.

To use hydraulic control well head displacement mechanism for enlargement of initial hole diameter.

Main machine technical parameter
Drilling depth	200m
Drilling diameter	300mm
End diameter	75mm
Drilling pipe diameter	50mm
Drilling angle	90° - 75°
Drilling weight (no include power)	975kg
Unity machine dimensions	2.75×0.95×1.6m
Spindle
Spindle speed	64, 128, 287, 557r/min
Spindle stroke	450mm
Hoist
Max. single line hoisting capacity	2400kg
Reel lifting speed	17, 35, 75, 151r/min
Reel diameter	140mm
Wire rope diameter	13mm
Wire rope cubic measure	35m
Hug floodgate diameter	260mm
Hug floodgate belt width	70mm
Distance between drill and hole	400mm
Power
Diesel engine	s1110 Model, 20HP
Electric Motor	Y160M—4 ,15kw 1440r/min
Mud pump
Type	Horizontal single urn twin-action
Displacement	170L/min
Maximum pressure	3.0Mpa
Work pressure	1.5Mpa
Water inlet caliber	40mm
Water to exit caliber	30mm
Triangle conveyer belt	B1728mm
Hydraulic pump
specification	CBT—F—314
Triangle conveyer belt	B1100×1
Application
Geology general check exploration, Earth physics exploration, sampling test in mining, water Well, Blast opening etc drilling engineering
