AJ-6500 High-quality Mature Technology Easy Operation Long Lifetime Ultrasound Therapy Machine

Specifications

Adopt digital integrated circuit, Interactive interface design, high definition LCD and internal circulation cooling system.



Ultrasound Therapy Machine AJ-6500











Ultrasonic therapy equipment is a kind of high-tech medical appliance which can be used to cure diseases by utilizing the tissue penetrability and energy aggradations owned by ultrasonic wave itself, focalize the ultrasonic wave outside the body on pathological-change tissues of organism and via the mechanical-energetic effect, thermal effect and cavitation effect of ultrasonic wave. It’s especially efficacious for chronic cervicitis, leukoplakia vulvae, condyloma and other diseases.







Functions & Curative Effects



*Adopting the therapy technique of high intensity focused ultrasound wave with precise location, high-level direction, non-invasive cure and no radiation-damages. The therapeutic effect is distinct with high safety.



*The therapy dosage is easy to be controlled. Some part of soft tissue will appear transient edema after the therapy, but the surface cell can be kept perfectly. The disease can be cured from inner to outside for keeping the surface tissue, and just needing short time for the recovery and keeping the surface tissue.



*Easily operation and fast therapy process. Normally one-time therapy could achieve the therapeutic purposes.







Features



*Adopt digital integrated circuit, Interactive interface design, high definition LCD and internal circulation cooling system.



*The therapeutic gun is designed as handheld which is according with ergonomics and easy to operate.



*Ultrasonic frequency, pulse frequency and output acoustic power are adjustable, and also could make the settlement of different working frequencies.



*The equipment is trolley type, moveable, and also has been equipped with castor for brake.



*Reserved up-gradation connector, which could be added or expanded new functions according to the user’s needs.







Specifications



Display	15 inch LCD touch screen (rotatable)
Input Power	≤650VA
Ultrasonic Wave Frequency	8MHz~12MHz
Ultrasonic Power	0~5.0W
Output pulse modulated sine wave, pulse frequency	0.1kHz~3.5kHz
Regular Time	0~300s/time
Therapeutic Depth	4-6mm; less than 8mm
Noise	≤65dB(A)
Drainage System	Dismountable
Parameter Setting Methods	Touch and Mouse
Output Acoustic Power	0-100%adjustable, ≤5W
Cine Loop	successive 256 frames
Auto save	Yes
Power Supply Range	AC-220V±22V 50Hz±10Hz
Operate System	WINCE
Control System	Embedded ARM
Focused Ultrasonic Therapeutic Gun	Integrity of Water and Electricity, Integrity of Electro-acoustic conversion
Probe connector	Two







Configurations



*Standard configurations: Main unit



                         One therapeutic probe for Cervicitis



                         Ten disposable sterile plastic parts



                         Two boxes of axenic gel



*Optional accessories: Leukoplakia Vulvae therapeutic gun
