malleable iron nipple/elbow/tee/plug/unions/bushing/cap/reducer/socket

Specifications

malleable iron pipe fittings
Standard:EN10242 ANSI
surface:galvanizedblack
Thread: ISO7/1, NPT
beaded/banded

malleable cast iron pipe fittings

Type

elbow, tee, reducer, cap, sockets , backnuts , flanges ,unions ,nipples bushings ,etc

size

1/8"--6''

Coatings

Cold galvanizing , hot galvanizing or black and so on.

Edges

Banded, beaded or plain

standard







1] American standard

Material:ASTM A-197 ,ASTM A47

Dimensions: ASME B16.B 16.14

Threads: ANSI B1.20.1









2]British standard

Material:ASTM-A197,ASTM A47

Dimension:BS EN 10242,BS 143&1256

Threads:ISO7/1









3]Din standard

Material:ASTM A-197 ,ASTM A47

Dimensions: ISO49,DIN2950,DIN En102452

Threads:ISO7/1

Mechsnicsl properties



Tensile strength300N/mm2,HardessHb163,Elongation6%.

Hydrostatic testing;test pressure=2.4Mpa,Working Pressure=2.0Mpa .

Others

.Packaging:In cartons or bags with/without pallet
