Help CenterQuick Adaptor for PVC/PE Pipe
US$ 10 - 200
MOQ: 10 Pieces
Key Specifications
Get Latest Price
Material:
Iron
Technics:
Casting
Type:
Other, Adaptor
Payment & Shipping
Payment Methods:
Port of Shipment:
TIANJIN OR QINGDAO
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Material
Iron
Technics
Casting
Type
Other, Adaptor
Place of Origin
Shanxi, China
Model Number
FA-restrained
Brand Name
ALLWIN or OEM
Connection
Female
Shape
Equal
Head Code
Other, Round
Quick Adaptor for PVC/PE Pipe
1) Standard:EN545/ISO4427
2) Epoxy inside and outside 250um
3) Size: DN50-300mm,OD63-400MM
4) Restrained Brass Ring
5) Gasket: EPDM/NBR
Material List
| No | Reference | Material | standard |
| 1 | Body | Ductile iron | EN1563 |
| 2 | Ring | Brass | |
| 3 | Rubber | EPDM/NBR | EN681/EN682 |
Dimensions
| No | DN | Pipe OD | PN | L | D | Weight |
| mm | mm | kg | ||||
| 1 | 50 | 63 | 16 | 55 | 183 | 2.40 |
| 2 | 60/65 | 63 | 16 | 58 | 183 | 2.70 |
| 3 | 60/65 | 75 | 16 | 58 | 183 | 2.80 |
| 4 | 80 | 90 | 16 | 60 | 200 | 3.60 |
| 5 | 100 | 110 | 16 | 68 | 220 | 3.80 |
| 6 | 125 | 125 | 16 | 70 | 250 | 4.90 |
| 7 | 125 | 140 | 16 | 75 | 250 | 5.00 |
| 8 | 150 | 160 | 16 | 80 | 285 | 6.20 |
| 9 | 200 | 200 | 16 | 93 | 340 | 9.60 |
| 10 | 200 | 225 | 16 | 93 | 340 | 10.00 |
| 11 | 250 | 250 | 16 | 95 | 400 | 11.50 |
| 12 | 300 | 315 | 16 | 100 | 455 | 13.80 |
| 13 | 400 | 400 | 16 | 100 | 580 | 25.00 |
Use:
Quick adaptor is suitabe for PVC/PE pipe .It has a gasket and a restained brass ring .
When you put the pipe into the quick adaptor body , the brass ring will fasten the pipeto avoid the pipe out of the adaptor .
The body is made by ductile iron material .
The gasket is EPDM material for drinkable water or NBR material for oil/industrial pipe line.
The surface with fusion bond epoxy or polyesrter coating which is suitable for drinkable water .
More Models for reference:
