Help CenterFlanged Adapter for Cast Iron Pipe
Related Products
-
DI Flanged Adapter for PE PipesUS$ 1,000 - 3,000MOQ: 1 Piece -
Ductile Iron Flanged Adapter With Wide Connect RangeUS$ 1,000 - 3,000MOQ: 1 Piece
-
Ductile Iron Flanged Adapter for DI,PVC and Steel PipeUS$ 1,000 - 3,000MOQ: 1 Piece
-
Ductile Iron Coupling for Ductile Iron PipeUS$ 1,000 - 3,000MOQ: 1 Piece
-
Ductile Iron or Carbon Steel Dismantling JointUS$ 1,000 - 2,000MOQ: 1 Piece
Specifications
DI Flange Adapter for cast iron pipe1.Siz range: DN50-2600mm
2.Working pressure PN10/16
3.EPDM/NBR rubber seal
Description of Quick Flange Adaptor For PE Pipe
Universal Flange adaptors facilitate the connection of plain ended pipe to flanged products , in the same range
of outside diameters, and multi-drilling flanges further simplify installation.To facilitate installation and avoid
possible creep under rising load, it is strongly recommended that the rubber sealing gaskets are well lubricated
with a suitable non-toxic soap solution before the introduction of the pipe. This practice should obviate the need
for retightening the fasteners after pressure testing, and further facilitate the seating of the joint components.
Materials of Flange Adaptor For PVC Pipe
| NO. | Description | Material |
| 1 | Body | Ductile iron |
| 2 | Bolts & nuts | Carbon Steel/ Stainles Steel |
| 3 | Rubber Seal | EPDM/NBR |
| 4 | Washer | Stainless Steel |
Specifications of Flange Adaptor For PVC pipe
Size Range: DN50-2000MM
Working pressure: PN10/PN16
Rubber Seal: EPDM/NBR
Angular Deflection ±3 degree
Media Temperature: Max 40°c
Non Tensile
Dacromet Coated Bolts and nuts
Fusion bonded epoxy powder coating for Body
USE: For cast iron, ductile iron, steel, UPVC, copper pipes
